Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
245
LC-30HV4U
LC-30HV4D
INTEGRATED CIRCUIT
IC101 VHiTPS819++-1Y J TPS819 AH
TRANSISTORS
Q101 VS2SC2712Y/-1Y J 2SC2712Y AB
Q102 VS2SC2712Y/-1Y J 2SC2712Y AB
Q103 VS2SC2712Y/-1Y J 2SC2712Y AB
Q104 VS2SC3928AR-1Y J 2SC3928AR AB
Q105 VS2SC3928AR-1Y J 2SC3928AR AB
Q106 VS2SC2712Y/-1Y J 2SC2712Y AB
DIODES
D101 RH-EX0879CEZZY J Zener Diode, 12V AD
D102 RH-PX0419CEZZY J Sleep Timer Indicator AC
D103 RH-PX0421CEZZY J POWER Indicator AD
D104 RH-PX0198TAZZY J OPC Indicator AC
CAPACITORS
C101 VCEAPF0JN107MY J 100 6.3V Electrolytic AD
C102 VCKYTV1CF225ZY J 2.2 16V Ceramic AB
C104 VCEAPF1CN106MY J 10 16V Electrolytic AD
C105 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R102 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R104 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R105 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R106 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R108 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R109 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R113 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R115 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R116 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P101 QPLGN0874TAZZY J Plug, 8-pin(RM) AD
RMC101 RRMCU0239CEZZ J Remote Control Sensor AG
SLD101 PSLDM4646CEFW J Shield AD
DUNTKB804DE02 (LC-30HV4U)
DUNTKB804DE03 (LC-30HV4D)
SPEAKER-L Unit (Display)
DUNTKB803DE02 (LC-30HV4U)
DUNTKB803DE03 (LC-30HV4D)
R/C, LED Unit (Display)
DIODES
D201 RH-EX1274CEZZY J Zener Diode, 13V AB
D202 RH-EX1274CEZZY J Zener Diode, 13V AB
CAPACITORS
C201 VCKYCY1HB102KY J 1000p 50V Ceramic AA
MISCELLANEOUS PARTS
FB201 RBLN-0210TAZZY J Ferrite Bead AB
FB202 RBLN-0210TAZZY J Ferrite Bead AB
J201 QJAKEA003WJZZ J Speaker Plug AD
P201 QPLGN0242CEZZ J Plug, 2-pin(SL) AA
P205 QLUGHA001WJZZY J Lug AD
DUNTKB805DE02 (LC-30HV4U)
DUNTKB805DE03 (LC-30HV4D)
SPEAKER-R Unit (Display)
DIODES
D203 RH-EX1274CEZZY J Zener Diode, 13V AB
D204 RH-EX1274CEZZY J Zener Diode, 13V AB
CAPACITORS
C202 VCKYCY1HB102KY J 1000p 50V Ceramic AA
MISCELLANEOUS PARTS
FB203 RBLN-0210TAZZY J Ferrite Bead AB
FB204 RBLN-0210TAZZY J Ferrite Bead AB
J202 QJAKEA003WJZZ J Speaker Plug AD
P202 QPLGN0242CEZZ J Plug, 2-pin(SR) AA
P206 QLUGHA001WJZZY J Lug AD
