Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
246
LC-30HV4U
LC-30HV4D
RDENCA009WJN3 (LC-30HV4U)
RDENCA009WJN1 (LC-30HV4D)
POWER Unit (Display)
INTEGRATED CIRCUITS
IC1 VHiNJM2375AD1 J NJM2375AD AL
IC2 VHiTNY264P/-1 J TNY264P AN
IC3 VHiHA17431UA4 J HA17431 AE
IC4 VHiHA17431UA4 J HA17431 AE
IC11 VHiHA17431UA4 J HA17431 AE
TRANSISTORS
Q1 VS2SK2917//-1 J 2SK2917 AT
Q2 VS2SC2873/Y-1 J 2SC2873 AD
Q3 VSDTB114EK/-1 J DTB114EK AD
Q5 VS2SK2717//-1 J 2SK2717 AP
Q6 VS2SC2873/Y-1 J 2SC2873 AD
Q9 VS2SK2717//-1 J 2SK2717 AP
Q10 VS2SC2873/Y-1 J 2SC2873 AD
Q13 VSDTA124EK/-1 J DTA124EK AB
Q14 VSDTC124EK/-1 J DTC124EK AB
Q17 VSDTD114EK/-1 J DTD114EK AC
Q18 VSDTC124EK/-1 J DTC124EK AB
Q22 VSDTA124EK/-1 J DTA124EK AB
Q23 VSDTA124EK/-1 J DTA124EK AB
DIODES
D1 VHDLN4SB60/-1 J Bridge Diode AK
D2 VHDFMDG26S/-1 J Diode AH
D3 VHD1SS193//-1 J Diode AB
D4 VHD1SS193//-1 J Diode AB
D5 VHD1SS193//-1 J Diode AB
D6 VHEHZU22B2/-1 J Zener Diode AC
D7 VHD1SS193//-1 J Diode AB
D8 VHD1SS193//-1 J Diode AB
D9 VHD1SS193//-1 J Diode AB
D10 VHD1SS193//-1 J Diode AB
D11 VHEHZU20B2/-1 J Zener Diode AC
D12 VHD1SS193//-1 J Diode AB
D18 VHDEG01C///-1 J Diode AD
D19 VHDEG01C///-1 J Diode AD
D20 VHDSFPL52V/-1 J Diode AD
D21 VHDFMB24L//-1 J Diode AG
D22 VHDFMB24L//-1 J Diode AG
D23 VHEHZU13B1/-1 J Zener Diode AC
D24 VHDFMB26L//-1 J Diode AH
D25 VHDFMB26L//-1 J Diode AH
D26 VHEHZU15B3/-1 J Zener Diode AC
D29 VHDSFPB69//-1 J Diode AE
D30 VHEHZU5.1B2-1 J Zener Diode AC
D31 VHD1SS193//-1 J Diode AB
D39 VHERLZ8.2A/-1 J Zener Diode AC
D44 VHD1SS193//-1 J Diode AB
D45 VHERLZ8.2A/-1 J Zener Diode AC
PACKAGED CIRCUITS
å PC1 VHPPS2581L2DW J Photo Coupler AE
å PC2 VHPPS2581L2DW J Photo Coupler AE
å PC4 VHPPS2581L2DW J Photo Couple AE
å PC6 VHPPS2581L2DW J Photo Coupler AE
å PC8 VHPPS2581L2DW J Photo Coupler AE
TH1 VHS8D2-10LD-1 J Thermistor AE
TH2 VHS8D2-10LD-1 J Thermistor AE
å VA1 VHVNV470D10-C J Varistor AE
å VA4 VHVNV470D10-C J Varistor AE
COILS AND TRANSFORMERS
å L1 RCiLZ1258SNEZ J Line Filter AN
å L2 RCiLZ1231SNEZ J Line Filter AS
L3 RCiLC1261SNEZ J Choke Coil AR
L4 RCiLC1262SNEZ J Choke Coil AF
L5 RCiLC1253SNEZ J Choke Coil AF
L7 RCiLC1252SNEZ J Choke Coil AE
å T1 RTRNP1226SNEZ J Transformer AQ
å T2 RTRNP1226SNEZ J Transformer AQ
å T3 RTRNP1227SNEZ J Transformer, P1227 AQ
å T4 RTRNP1227SNEZ J Transformer, P1227 AQ
å T6 RTRNP1228SNEZ J Transformer, P1228 AQ
CAPACITORS
å C1 RC-M2E224RESC J 0.22 275V Film AE
å C3 RC-M2E224RESC J 0.22 275V Film AE
å C4 RC-M2E473RESC J 0.047 275V Film AE
C5 RC-M2W105HCEZ J 1 450V Film AH
C6 RCDE0707R221S J 220p 2kV Ceramic AD
C7 RC-E2W686PBFA J 68 450V Electrolytic AM
C8 RC-E2W686PBFA J 68 450V Electrolytic AM
C10 VCKYCY1HB103K J 0.01 50V Ceramic AA
C11 VCKYTV1CB474K J 0.47 16V Ceramic AC
C14 RC-E1H157SKZE J 150 50V Electrolytic AD
C15 RCDE0907R471S J 470p 2kV Ceramic AC
C16 RCDE0907R471S J 470p 2kV Ceramic AC
C17 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C18 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C19 VCKYCY1HB152K J 1500p 50V Ceramic AA
C20 VCKYCY1HB103K J 0.01 50V Ceramic AA
C21 RCDE0907R471S J 470p 2kV Ceramic AC
C22 RCDE0907R471S J 470p 2kV Ceramic AC
C23 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C24 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C25 VCKYTV1HB152K J 1500p 50V Ceramic AA
C26 VCKYCY1HB103K J 0.01 50V Ceramic AA
C27 VCKYCY1HF473Z J 0.047 50V Ceramic AA
C28 RC-E1H105SNPR J 1 50V Electrolytic AC
C29 VCKYCY1HB222K J 2200p 50V Ceramic AA
C36 RC-E2G226KMXZ J 22 400V Electrolytic AH
C37 RCDE0705SL101 J 100p 2kV Ceramic AD
C38 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C39 RC-E1H226SKZE J 22 50V Electrolytic AC
C40 RC-E1E227SNHC J 220 25V Electrolytic AE
C41 RC-E1E227SNHC J 220 25V Electrolytic AE
C42 RC-E1E227SNHC J 220 25V Electrolytic AE
C43 RC-E1E227SNHC J 220 25V Electrolytic AE
C44 RC-E1E227SNHC J 220 25V Electrolytic AE
C45 VCKYCY1AB474K J 0.47 10V Ceramic AC
C46 RC-E1E227SNHC J 220 25V Electrolytic AE
C47 RC-E1E227SNHC J 220 25V Electrolytic AE
C48 RC-E1E227SNHC J 220 25V Electrolytic AE
C52 RC-E1E227SNHC J 220 25V Electrolytic AE
C57 RC-E1A227SKZE J 220 10V Electrolytic AC
C58 RC-E1A107SKZE J 100 10V Electrolytic AC
C59 VCKYCY1EB104KY J 0.1 25V Ceramic AB
å C72 RCDE1010E222M J 2200p 250V Ceramic AD
å C73 RCDE1010E222M J 2200p 250V Ceramic AD
å C74 RCDE1010E222M J 2200p 250V Ceramic AD
C91 VCKYCY1HB103K J 0.01 50V Ceramic AA
C94 RC-E1H105SNPR J 1 50V Electrolytic AC
C95 VCKYTV1CB224K J 0.22 16V Ceramic AB
C96 VCKYCY1HB223K J 0.022 50V Ceramic AB
C97 VCKYCY1HB103K J 0.01 50V Ceramic AA
C98 RCDE0705SL101 J 100p 2kV Ceramic AD
C99 VCKYCY1HB103K J 0.01 50V Ceramic AA
RESISTORS
R1 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R2 VRS-TS2AD105J J 1M 1/10W Metal Oxide AA
R3 VRS-TS2AD105J J 1M 1/10W Metal Oxide AA
R4 VRS-TS2AD153J J 15k 1/10W Metal Oxide AA
R5 VRS-TS2AD223J J 22k 1/10W Metal Oxide AA
R6 RR-ERQ14AJ120 J 12 1/4W Metal Oxide AD
R7 RR-HRNMR15J2C J 0.15 2W Metal Oxide AD
R8 VRS-TS2AD101J J 100 1/10W Metal Oxide AA
R9 VRS-TS2AD821J J 820 1/10W Metal Oxide AA
R10 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R11 RR-HRSM3R0J3W J 3 3W Metal Oxide AD
R12 VRS-RE3LA330J J 33 3W RSI Carbon AD
R13 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R14 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R15 VRS-TS2AD103J J 10k 1/10W Metal Oxide AA
R16 VRS-TS2AD183J J 18k 1/10W Metal Oxide AA
To Next Page
