Sharp LC-30HV4U User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
247
LC-30HV4U
LC-30HV4D
RDENCA009WJN3 (LC-30HV4U)
RDENCA009WJN1 (LC-30HV4D)
POWER Unit (Display) (Continued)
R17 VRS-TS2AD122J J 1.2k 1/10W Metal Oxide AA
R18 VRS-TW2ED821J J 820 1/4W Metal Oxide AA
R19 VRS-TW2ED102J J 1k 1/4W Metal Oxide AA
R20 VRS-TX2HD221J J 220 1/2W Metal Oxide AB
R21 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R22 VRS-TS2AD680J J 68 1/10W Metal Oxide AA
R23 VRS-TS2AD101J J 100 1/10W Metal Oxide AA
R27 RR-HRSM3R0J3W J 3 3W Metal Oxide AD
R28 VRS-RE3LA330J J 33 3W RSI Carbon AD
R29 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R30 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R31 VRS-TS2AD103J J 10k 1/10W Metal Oxide AA
R32 VRS-TS2AD183J J 18k 1/10W Metal Oxide AA
R33 VRS-TS2AD122J J 1.2k 1/10W Metal Oxide AA
R34 VRS-TW2ED561J J 560 1/4W Metal Oxide AA
R35 VRS-TW2ED102J J 1k 1/4W Metal Oxide AA
R36 VRS-TX2HD221J J 220 1/2W Metal Oxide AB
R37 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R38 VRS-TS2AD680J J 68 1/10W Metal Oxide AA
R39 VRS-TS2AD101J J 100 1/10W Metal Oxide AA
R43 VRS-TS2AD562J J 5.6k 1/10W Metal Oxide AA
R44 VRS-TS2AD513J J 51k 1/10W Metal Oxide AA
R58 VRS-TX2HD152J J 1.5k 1/2W Metal Oxide AB
R59 RR-ERQ14AJ3R3 J 3.3 1/4W Carbon AD
R60 VRS-TS2AD221J J 220 1/10W Metal Oxide AA
R61 VRS-TS2AD101J J 100 1/10W Metal Oxide AA
R62 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R63 VRS-TS2AD562J J 5.6k 1/10W Metal Oxide AA
R64 VRS-TS2AD362F J 3.6k 1/10W Metal Oxide AA
R65 VRS-TS2AD181F J 180 1/10W Metal Oxide AA
R66 VRS-TS2AD102F J 1k 1/10W Metal Oxide AA
R67 VRS-TS2AD101J J 100 1/10W Metal Oxide AA
R68 VRS-TS2AD221J J 220 1/10W Metal Oxide AA
R69 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R71 VRS-TS2AD562F J 5.6k 1/10W Metal Oxide AA
R72 VRS-TS2AD301F J 300 1/10W Metal Oxide AA
R73 VRS-TS2AD102F J 1k 1/10W Metal Oxide AA
R81 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R82 VRS-TS2AD103J J 10k 1/10W Metal Oxide AA
R83 VRS-TS2AD222J J 2.2k 1/10W Metal Oxide AA
R96 VRS-TX2HD274J J 270k 1/2W Metal Oxide AB
R97 VRS-TS2AD221J J 220 1/10W Metal Oxide AA
R105 VRS-TP2BD754F J 750k 1/8W Metal Oxide AA
R106 VRS-TP2BD824F J 820k 1/8W Metal Oxide AA
R107 VRS-TS2AD103F J 10k 1/10W Metal Oxide AA
R108 VRS-TS2AD223J J 22k 1/10W Metal Oxide AA
R109 VRS-TS2AD104J J 100k 1/10W Metal Oxide AA
å R110 RR-RCR60-106J J 10M 1/2W Metal Oxide
R115 VRS-TS2AD100J J 10 1/10W Metal Oxide AA
R116 VRS-TP2BD824F J 820k 1/8W Metal Oxide AA
R117 VRS-TP2BD914F J 910k 1/8W Metal Oxide AA
R118 VRS-TS2AD103F J 10k 1/10W Metal Oxide AA
R119 VRS-TS2AD102J J 1k 1/10W Metal Oxide AA
R120 VRS-TS2AD221J J 220 1/10W Metal Oxide AA
R121 VRS-TS2AD152J J 1.5 1/10W Metal Oxide AA
MISCELLANEOUS PARTS
å F1 QFS-A1130SNEZ J Fuse, T3.15A 250V,TR-5 382 AF
å F3 QFS-A1129SNEZ J Fuse, T2A 250V TR-5 382 AF
å F9 QFS-T1099SNEZ J Fuse, X25 136°C 2A P130A AE
å CN1 QSOCA1014SNEZ J Inlet, AC-M15PB58 AF
CN2 QCNCM1706SNEZ J Connector, B5P10S-VH AF
CN3 QCNCM1771SNEZ J Connector, BM07B-SRSS-TB AF
CN4 QCNCM1373SNEZ J Connector, B6B-PH-K-S AD
CN5 QCNCM1395SNEZ J Connector, B5B-PH-K-S AC
CN6 QCNCM1396SNEZ J Connector, B2B-PH-K-S AB
CN7 QCNCM1580SN1J J Connector, B10B-EH AE
å RL1 RRLYD1010SNEZ J Relay, JZ1AFS-5V-TV AP
LANGK3001SNEZ J Inlet Angle AG
PRDAF3000SNEZ J Heat Sink- A AG
PRDAF3001SNEZ J Heat Sink- B AG
PRDAF3003SNEZ J Heat Sink- D AG
QTAND1017SNEZ J Lug AC
å PZETZ0028CEKZ J Insulation Sheet AR
LX-BZ1001SNEZ J Rivet AB
LHLDW1012SNEZ J UAMS-07-0 AC

Sharp LC-30HV4U Specifications

General

Brand	Sharp
Model	LC-30HV4U
Category	LCD TV
Language	English
