Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
60
LC-32AX3H/M/X
LC-37AX3H/M/X
DUNTKD513DE01 (LC-32AX3M) DUNTKD513DE04 (LC-37AX3M)
DUNTKD513DE02 (LC-32AX3H) DUNTKD513DE05 (LC-37AX3H)
DUNTKD513DE03 (LC-32AX3X) DUNTKD513DE06 (LC-37AX3X)
AV Unit (Continued)
Q2703 VSDTC314TK/-1Y J DTC314TK AC
Q2704 VS2SC3928AR-1Y J 2SC3928AR AB
Q2705 VSRN1104///-1Y J RN1104 AB
Q2706 VSRN2104///-1Y J RN2104 AB
Q2707 VS2SA1530AR-1Y J 2SA1530AR AB
Q2708 VSRN1104///-1Y J RN1104 AB
Q3905 VSRN1102///-1Y J RN1102 AB
Q5706 VSRN1102///-1Y J RN1102 AB
Q5707 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D1100 VHD1SS390++-1Y J Diode AB
D1101 RH-EX0677GEZZY J Zener Diode, 33V AC
D1102 RH-EX0253TAZZY J Zener Diode, 3.5V AC
D1103 VHD1SS390++-1Y J Diode AB
D1104 VHD1SS390++-1Y J Diode AB
D1206 RH-EX0265TAZZY J Zener Diode, 10V AB
D1209 RH-EX0265TAZZY J Zener Diode, 10V AB
D1210 RH-EX0265TAZZY J Zener Diode, 10V AB
D1211 RH-EX0265TAZZY J Zener Diode, 10V AB
D1212 RH-EX0265TAZZY J Zener Diode, 10V AB
D1213 RH-EX0265TAZZY J Zener Diode, 10V AB
D1214 RH-EX0265TAZZY J Zener Diode, 10V AB
D1215 RH-EX0265TAZZY J Zener Diode, 10V AB
D1216 RH-EX0265TAZZY J Zener Diode, 10V AB
D1217 RH-EX0265TAZZY J Zener Diode, 10V AB
D1218 RH-EX0265TAZZY J Zener Diode, 10V AB
D1219 RH-EX0265TAZZY J Zener Diode, 10V AB
D1220 RH-EX0265TAZZY J Zener Diode, 10V AB
D1221 RH-EX0265TAZZY J Zener Diode, 10V AB
D1222 RH-EX0265TAZZY J Zener Diode, 10V AB
D1223 RH-EX0265TAZZY J Zener Diode, 10V AB
D1224 RH-EX0265TAZZY J Zener Diode, 10V AB
D1225 RH-EX0265TAZZY J Zener Diode, 10V AB
D1226 RH-EX0265TAZZY J Zener Diode, 10V AB
D1227 RH-EX0265TAZZY J Zener Diode, 10V AB
D1228 RH-EX0265TAZZY J Zener Diode, 10V AB
D1900 VHDSFPB54//2EY J Diode AC
D1901 VHDBAS316//-1Y J Diode AB
D1904 RH-EX0267TAZZY J Zener Diode, 12V AB
D1905 RH-EX0267TAZZY J Zener Diode, 12V AB
D1906 VHDBAS316//-1Y J Diode AB
D1907 VHDSFPB54//2EY J Diode AC
D2501 VHDBAS316//-1Y J Diode AB
D2502 VHDBAS316//-1Y J Diode AB
D2503 VHDBAS316//-1Y J Diode AB
D2700 VHDBAS316//-1Y J Diode AB
D2701 VHDLi114+++-1Y J Diode AC
D2702 VHDLi114+++-1Y J Diode AC
D2703 VHDLi114+++-1Y J Diode AC
D2704 VHDLi114+++-1Y J Diode AC
D2706 RH-EX1283CEZZY J Zener Diode, 18V AB
D2707 RH-EX1283CEZZY J Zener Diode, 18V AB
D2708 RH-EX1283CEZZY J Zener Diode, 18V AB
D2709 RH-EX1283CEZZY J Zener Diode, 18V AB
D2711 VHDBAS316//-1Y J Diode AB
D2712 VHDBAS316//-1Y J Diode AB
D2714 VHDBAS316//-1Y J Diode AB
D2716 VHDBAS316//-1Y J Diode AB
D2717 VHDBAS316//-1Y J Diode AB
D5705 VHDBAS316//-1Y J Diode AB
D5707 VHDBAS316//-1Y J Diode AB
PACKAGED CIRCUITS
X1100 RCRSAA029WJZZ J Crystal, 4MHz AF
X1900 RCRSCA108WJZZY J Crystal, 28.322MHz AF
X2500 RCRSB0250GEZZ+ J Crystal, 18.432MHz AG
FILTER AND COILS
FL1200 RFiLN0017TAZZY J Filter AC
FL1201 RFiLN0017TAZZY J Filter AC
FL1202 RFiLN0017TAZZY J Filter AC
FL1203 RFiLN0017TAZZY J Filter AC
FL1204 RFiLN0017TAZZY J Filter AC
FL1205 RFiLN0017TAZZY J Filter AC
FL1206 RFiLN0017TAZZY J Filter AC
FL1207 RFiLN0017TAZZY J Filter AC
FL1208 RFiLN0017TAZZY J Filter AC
FL1209 RFiLN0017TAZZY J Filter AC
FL1214 RFiLNA118WJZZY J Filter AC
FL1215 RFiLNA118WJZZY J Filter AC
FL1216 RFiLNA118WJZZY J Filter AC
FL1217 RFiLNA118WJZZY J Filter AC
FL1218 RFiLNA118WJZZY J Filter AC
FL1900 RFiLNA027WJZZY J Filter AD
FL1901 RFiLNA027WJZZY J Filter AD
FL1902 RFiLNA027WJZZY J Filter AD
L1102 VPD9M1R2JR66NY J Peaking 1.2µH AB
L1103 VPD9M1R2JR66NY J Peaking 1.2µH AB
L1104 VPCLN100MR36NY J Peaking 10µH AB
L1105 VPCLN100MR36NY J Peaking 10µH AB
L1107 VPD9M330J3R6NY J Peaking 33µH AC
L1900 RCiLFA134WJZZY J Coil AF
L1901 RCiLFA134WJZZY J Coil AF
L1902 RCiLFA134WJZZY J Coil AF
L1903 RCiLFA134WJZZY J Coil AF
L2700 RCiLPA001WJZZY J Coil AF
L2701 RCiLPA001WJZZY J Coil AF
L2702 RCiLPA001WJZZY J Coil AF
L2703 RCiLPA001WJZZY J Coil AF
SF1101 RFiLC0445CEZZ J S.A.W. Filter AM
SF1102 RFiLC0444CEZZ J S.A.W. Filter AN
TRANSFORMER
T2700 RRLYDA002WJZZY J Relay AK
CAPACITORS
C1100 VCERML1EN336MY J 33 25V Electrolytic AC
C1101 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1102 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1103 VCERMZ1CN477MY J 470 16V Electrolytic AE
C1104 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1105 VCERMZ1CN107MY J 100 16V Electrolytic AD
C1106 VCERML1HN107MY J 100 50V Electrolytic AE
C1107 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1108 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1109 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1110 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1111 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1112 VCERML1CN106MY J 10 16V Electrolytic AC
C1113 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1114 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1115 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1116 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1117 RC-KZA073WJZZY J 10 16V Ceramic AD
C1118 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1119 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1120 VCERMZ1VN106MY J 10 35V Electrolytic AC
C1121 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1122 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1123 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1124 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1125 VCERMZ1CN107MY J 100 16V Electrolytic AD
C1126 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1127 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1128 VCCCCY1HH391JY J 390p 50V Ceramic AB
C1129 VCKYTV1CB224KY J 0.22 16V Ceramic AB
C1130 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1131 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C1132 VCERMZ1CN227MY J 220 16V Electrolytic AD
C1134 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1135 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1136 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1137 VCCCCY1HH120JY J 12p 50V Ceramic AA
C1206 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1207 VCCCCY1HH560JY J 56p 50V Ceramic AB
