Sharp LC-32AX3H - Replacement Parts List

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
59
LC-32AX3H/M/X
LC-37AX3H/M/X
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such fea-
tures are identified by å and shaded areas in the Replacement
Parts Lists and Schematic Diagrams. The use of a substitute re-
placement part which does no have the same safety characteristic
as the factory recommended replacement parts shown in this serv-
ice manual may create shock, fire or other hazards.
“HOW TO ORDER REPLACEMENT PARTS”
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
PRINTED WIRING BOARD ASSEMBLYS
(NOT REPLACEMENT ITEM)
LC-32AX3H
DUNTKD513DE02 – AV Unit —
DUNTKD514DE02 – KEY Unit —
DUNTKD515DE02 – R/C,LED Unit —
DUNTKD558FE02 – MAIN Unit —
RDENCA145WJQZ – POWER Unit —
LC-32AX3M
DUNTKD513DE01 – AV Unit —
DUNTKD514DE01 – KEY Unit —
DUNTKD515DE01 – R/C,LED Unit —
DUNTKD558FE01 – MAIN Unit —
RDENCA156WJQZ – POWER Unit —
LC-32AX3X
DUNTKD513DE03 – AV Unit —
DUNTKD514DE03 – KEY Unit —
DUNTKD515DE03 – R/C,LED Unit —
DUNTKD558FE03 – MAIN Unit —
RDENCA145WJQZ – POWER Unit —
LC-37AX3H
DUNTKD513DE05 – AV Unit —
DUNTKD514DE05 – KEY Unit —
DUNTKD515DE05 – R/C,LED Unit —
DUNTKD558FE05 – MAIN Unit —
RDENCA145WJQZ – POWER Unit —
LC-37AX3M
DUNTKD513DE04 – AV Unit —
DUNTKD514DE04 – KEY Unit —
DUNTKD515DE04 – R/C,LED Unit —
DUNTKD558FE04 – MAIN Unit —
RDENCA156WJQZ – POWER Unit —
LC-37AX3X
DUNTKD513DE06 – AV Unit —
DUNTKD514DE06 – KEY Unit —
DUNTKD515DE06 – R/C,LED Unit —
DUNTKD558FE06 – MAIN Unit —
RDENCA145WJQZ – POWER Unit —
LCD PANEL
DUNTKD513DE01 (LC-32AX3M) DUNTKD513DE04 (LC-37AX3M)
DUNTKD513DE02 (LC-32AX3H) DUNTKD513DE05 (LC-37AX3H)
DUNTKD513DE03 (LC-32AX3X) DUNTKD513DE06 (LC-37AX3X)
AV Unit
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCUCA029WJZZ J 32" LCD Panel Module Ass'y ED
RLCUCA030WJZZ J 37" LCD Panel Module Ass'y EZ
Ref. No. Part No. ★ Description Code
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU1100 RTUNQA021WJZZ J Tuner AW
INTEGRATED CIRCUITS
IC1100 VHiBA7655AF-1Y J BA7655AF AG
IC1103 VHiM62332FP-1Y J M62332FP AL
IC1104 VHiTDA9885+-1Y J TDA9885TS/V3 AP
IC1202 VHiMM1506XN-1Y J MM1506XNRE AD
IC1203 VHiMM1630EQ-1Q J MM1630EQ AT
IC1902 VHi24LC2BiNEES J 24LC02B-I/SN AH
IC1904 VHiSii9021+-1Q J SIL9021CTU BC
IC1905 VHiAK4384ET-1Y J AK4384ET AG
IC1906 VHiNJM2750M-1Y J NJM2750M(TE2) AH
IC2500 VHiNJU26901-1Y J NJU26901E2 AS
IC2501 VHiMSP3453G-1Q J MSP3453-QA-B3 BB
IC2502 VHiLVX125FT-1Y J TC74LVX125FT AG
IC2503 VHiT7SET08U1EY J TC7SET08FU AC
IC2504 VHiNJM4565M-1Y J NJM4565M AE
IC2506 VHiBH3544F+-1Y J BH3544F-E2 AE
IC2701 VHiTA2024++-1Y J TA2024 AX
IC2703 VHiBD4742G+-1Y J BD4742G-TR AD
IC5701 VHiPQ09DZ1U-1Y J PQ09DZ1U AG
IC5702 VHiBA08SFP+-1Y J BA08SFP-E2 AG
IC5703 VHiPQ1R25++-1Y J PQ1R25 AD
IC5704 VHiPQ018EZ5-1Y J PQ018EZ5MZP AF
IC5706 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC5707 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
TRANSISTORS
Q1100 VS2SA1530AR-1Y J 2SA1530AR AB
Q1101 VS2SC2735//1EY J 2SC2735 AC
Q1102 VS2SC2735//1EY J 2SC2735 AC
Q1103 VS2SA1530AR-1Y J 2SA1530AR AB
Q1104 VS2SC3928AR-1Y J 2SC3928AR AB
Q1105 VS2SC3928AR-1Y J 2SC3928AR AB
Q1206 VSDTC314TK/-1Y J DTC314TK AC
Q1207 VSDTC314TK/-1Y J DTC314TK AC
Q1208 VSRN1104///-1Y J RN1104 AB
Q1209 VSRN1104///-1Y J RN1104 AB
Q1210 VSRN1104///-1Y J RN1104 AB
Q1215 VS2SA1530AR-1Y J 2SA1530AR AB
Q1216 VS2SA1530AR-1Y J 2SA1530AR AB
Q1217 VS2SK536///-1Y J 2SK536 AE
Q1218 VS2SK536///-1Y J 2SK536 AE
Q1219 VSRN1104///-1Y J RN1104 AB
Q1220 VSRN1104///-1Y J RN1104 AB
Q1900 VS2SK536///-1Y J 2SK536 AE
Q1901 VS2SK536///-1Y J 2SK536 AE
Q1902 VSRN1104///-1Y J RN1104 AB
Q1903 VSRN1104///-1Y J RN1104 AB
Q1904 VSRN2104///-1Y J RN2104 AB
Q1905 VSRN1104///-1Y J RN1104 AB
Q2500 VS2SC3928AR-1Y J 2SC3928AR AB
Q2501 VSRN1104///-1Y J RN1104 AB
Q2700 VS2SA1530AR-1Y J 2SA1530AR AB
Q2701 VSRN1102///-1Y J RN1102 AB
Q2702 VSRN1102///-1Y J RN1102 AB
