Sharp LC-32AX3H - Cabinet and Mechanical Parts

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
76
LC-32AX3H/M/X
LC-37AX3H/M/X
1 CCABAB073WJ02 J Cabinet A Ass’y BK
1-1 Not Available – Cabinet A —
1-2 GCOVAB240WJSA J R/C, LED Cover
1-3 HBDGBA015WJSA J "SHARP" Badge AH
1-4 PSPAHA607WJZZ J Mask Spacer (Side), x2
1-5 PSPAHA608WJZZ J Mask Spacer (Top/Bottom), x2
2 CCABBA636WJ02 J Cabinet B Ass’y BR
(LC-32AX3H/M)
2 CCABBA698WJ01 J Cabinet B Ass’y BR
(LC-32AX3X)
2-1 Not Available – Cabinet B —
2-2 GCOVAB225WJKA J Terminal Cover
2-3 LHLDWA055WJKZ J Wire Holder AC
2-4 PSPAHA413WJZZ J Spacer, x2 AB
3 CHNG-A104WJN2 J Stand Hinge Ass’y BK
3-1 Not Available – Stand Hinge —
3-2 GDAi-A117WJF8 J Swivel Base AP
3-3 GDAi-A184WJSB J Stand Support
3-4 LX-NZA013WJFN J Nut, x1 AE
3-5 PSPAZA714WJZZ J Spacer, x2
3-6 XCSS750P30000 J Screw, x5
4 CDAi-A185WJN2 J Stand Base Ass’y BL
4-1 Not Available – Stand Base —
4-2 LANGKA438WJSA J Base Angle BC
4-3 PSPAHA544WJZZ J Spacer, x1 AB
4-4 PSPAZA761WJZZ J Leg Cushion, x2 AD
4-5 PSPAZA762WJZZ J Leg Cushion-B, x2 AD
4-6 PSPAZA763WJZZ J Leg Cushion-C, x4 AD
4-7 XEBS940P12000 J Screw, x10 AB
5 CCOVAB340WJ01 J Top Cover Ass’y AM
5-1 Not Available – Top Cover —
5-2 JBTN-A459WJKA J Power Button
5-3 JBTN-A460WJKA J Operation Button
5-4 MSPRCA049WJFW J Spring, for Power Button AC
6 RLCUCA029WJZZ J 32" LCD Panel Module Ass’y ED
7 LANGTA249WJFW J Center Angle AY
8 LCHSMA227WJKA J Chassis Frame AK
9 GCOVAB166WJKB J Hinge Cover AP
10 GCOVAB243WJKA J ID Cover AD
11 HiNDPB557WJSA J Model Label (LC-32AX3H) AG
11 HiNDPB558WJSA J Model Label (LC-32AX3M) AG
11 HiNDPB559WJSA J Model Label (LC-32AX3X) AG
12 Not Available – Serial No. Label —
13 RSP-ZA120WJZZ J Speaker Box (Left) AU
14 RSP-ZA121WJZZ J Speaker Box (Right) AU
15 NSFTZA144WJFN J Shaft Screw AC
16 PSLDMA769WJFW J Tuner Shield AF
17 PSLDMA779WJFW J PWB Shield (Bottom) AM
18 PSLDMA833WJFW J PWB Shield (Top) AL
19 PSPAZA663WJKZ J Spacer (IC3301) AD
20 QCNW-D769WJQZ J Connecting Cord AG
21 QCNW-D781WJQZ J Connecting Cord AK
22 QCNW-D783WJQZ J Connecting Cord AK
23 QCNW-D846WJQZ J Connecting Cord AF
24 QCNW-E011WJQZ J Connecting Cord AG
25 QCNW-E012WJQZ J Connecting Cord AG
26 QCNW-E013WJQZ J Connecting Cord AE
27 QCNW-E014WJPZ J Connecting Cord AN
28 QCNW-E015WJQZ J Connecting Cord AG
29 QCNW-E016WJQZ J Connecting Cord AH
30 QCNW-E017WJPZ J Connecting Cord AX
31 QCNW-E018WJQZ J Connecting Cord AM
32 XBBS740P06000 J Screw, x7 AA
33 XBPS730P04WS0 J Screw, x2 AA
34 XBPS730P08WS0 J Screw, x19 AH
35 XBPS830P06000 J Screw, x1 AA
CABINET AND MECHANICAL PARTS
(LC-32AX3H/M/X)
36 XEBS930P08000 J Screw, x14 AA
37 XEBSN40P10000 J Screw, x3 AB
38 XBBS930P06000 J Screw, x4 AA
39 XBBS940P08000 J Screw, x2 AB
40 XBBSN50P12JS0 J Screw, x4 AF
41 XEBS940P16000 J Screw, x15 AB
42 XJBS850P25000 J Screw, x5 AC
43 LCRA-A012WJZZ J Clamp (LC-32AX3X) AG
44 PFLT-A062WJZZ J Felt (LC-32AX3X) AG
45 PMLT-A141WJZZ J Spacer (LC-32AX3X) AF
46 PMLT-A181WJZZ J Spacer (LC-32AX3X) AE
47 PMLT-A240WJZZ J Spacer (LC-32AX3X) AK
48 PSLDMA433WJZZ J Gasket (LC-32AX3X) AE
49 PSLDMA646WJZZ J Gasket (LC-32AX3X) AQ
50 RCORFA039WJZZ J Ferrite Core, x2 AG
(LC-32AX3X)
51 PSLDMA710WJFW J MDMI Shield AD
52 PRDARA263WJFW J Heat Sink AE
53 PSPAZA958WJKZ J Spacer (IC1203) AD
54 XBPS730P06WS0 J Screw, x2 AA
55 LHLDW0016PEKZ J Wire Holder, x2 AB
56 LHLDW1205CEZZ J Wire Holder, x1 AC
