Sharp LC-32D44E User Manual

LC32D44E/S/RU-BK/GY (1st Eddition)
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE266FM01 AR N R KEY Unit
N DUNTKE449FM02 CP N R MAIN Unit
N DUNTKE457FM02 AQ N R LED Unit
N DUNTKE491FM01 AY N R MINI-AV Unit
N RUNTKA396WJQZ BV N P POWER/INVERTER Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
N R1LK315T3GW30Y N J 32" LCD Panel Module
[3] DUNTKE266FM01(KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug 5Pin(KM)
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch CH UP
S152 QSW-K0003AJZZ+ AB J Switch CH DOWN
S153 QSW-K0003AJZZ+ AB J Switch CH INPUT
S154 QSW-K0003AJZZ+ AB J Switch VOL UP
S155 QSW-K0003AJZZ+ AB J Switch VOL DOWN
S156 QSW-K0003AJZZ+ AB J Switch CH MENU
S157 QSW-K0003AJZZ+ AB J Switch CH POWER
[4] DUNTKE449FM02 (MAIN Unit)
C201 VCEASX1AN336MY AC J Capacitor 33 10V Electrolytic
C207 VCEASX1CN477MY AE J Capacitor 470 16V Electrolytic
C209 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C210 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C213 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C214 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C215 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C216 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C217 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C218 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C219 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C220 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C221 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C222 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C223 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C224 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C225 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C226 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C227 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C228 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C229 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C230 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C231 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C232 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C233 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C234 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C235 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C236 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C237 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C238 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C239 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C240 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C241 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C242 VCKYCZ1EF104ZY AA J
Capacitor 0.1 25V Ceramic
C243 V
CKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C244 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C245 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C246 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C247 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C248 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C249 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C250 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C251 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C252 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C253 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C254 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C255 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C256 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C269 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C271 VCEASX1CN107MY AC J Capacitor 100 16V Electrolytic
C1005 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1006 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1007 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1008 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1009 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C1010 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
