LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 19
14. IC8103 (VHIT3Z18AFG-1Q)
Single Link LCD Receiver
The LVDS is essentially a signaling method used for high-speed transmission of binary data over copper.
It uses a lower voltage swing than other transmission standards. This low voltage differential is what delivers higher data transmission speeds and
inherently greater bandwidth at lower power consumption.
This new technology not only addresses the needs of today’s high performance data transmission application, but also the needs of future applica-
tion.
This LVDS receiver IP supports Single Link transmission between Host and Flat Panel Display. The receiver recovers the LVDS data and converts
into CMOS data. An on-chip PLL synchronizes the received clock with the parallel data and then all are transmitted to the parallel output port of the
receiver.
Description:
• Supports Single Link (Single Input to Single Output) up to 135MHz dot clock for SXGA+ (input clock frequency: 25 to 135MHz)
• PLL requires no external components
• Clock strobe edge selectable
• Support 10-bit color
• Power down mode
Pin No. Pin Name I/O Function Name Pin No. Pin Name I/O Function Name
1 PLLAVD 1.5V E1AVDLIVC 141 SCLK OUT BT4VIC1
2 PLLAVS GND E1AVSLIVC 142 SDT I/O BD4THVIC1
3 VSSAGND45L GND Z7RSTAGND45L 143 vext1103 1.5V SDRAMVDE1
4 VDDSAVCC4 3.3V Z7RSTAVCC4 144 VDDC 1.5V VDDC
5 VSSAGND45C GND Z7RSTAGND45C 145 RESET IN SMTCIF
6 VDDSAVCC5 3.3V Z7RSTAVCC5 146 CMOS_IN IN IBUFDIF
7 BR0_M OUT Z7RSDST 147 OS_SEL IN TLCHTHDVIC1
8 BR0_P OUT Z7RSDST 148 OS_ON IN TLCHTHDVIC1
9 BR1_M OUT Z7RSDST 149 BANK_SEL IN TLCHTHDVIC1
10 BR1_P OUT Z7RSDST 150 TEMP[2] IN TLCHTHDVIC1
11 BR2_M OUT Z7RSDST 151 vgnd87 GND SDRAMVSE
12 BR2_P OUT Z7RSDST 152 TEMP[1] IN TLCHTHDVIC1
13 BR3_M OUT Z7RSDST 153 TEMP[0] IN TLCHTHDVIC1
14 BR3_P OUT Z7RSDST 154 REV_MODE IN TLCHTHDVIC1
15 BCLK_M OUT Z7RSDST 155 HSCAN IN TLCHTHDVIC1
16 BCLK_P OUT Z7RSDST 156 VSCAN IN TLCHTHDVIC1
17 VDDSAVCC4 3.3V Z7RSTAVCC4 157 vext1105 1.5V SDRAMVDE1
18 VSSDGND1 GND Z7RSTDGND1 158 VSS12 GND VSS12
19 VDDCDVCC1 1.5V Z7RSTDVCC1 159 SELLVDS IN TLCHTHUVIC1
20 VSSAGND45C GND Z7RSTAGND45C 160 SSCLK I/O BD8SCIF
21 VDDSAVCC5 3.3V Z7RSTAVCC5 161 EXCLK IN IBUFIF
22 BG0_M OUT Z7RSDST 162 VDDC 1.5V VDDC
23 BG0_P OUT Z7RSDST 163 VSSAGND1L GND Z7LVRAGND1L
24 BG1_M OUT Z7RSDST 164 RA_M IN Z7LVRXIO
25 BG1_P OUT Z7RSDST 165 RA_P IN Z7LVRXIO
26 BG2_M OUT Z7RSDST 166 RB_M IN Z7LVRXIO
27 BG2_P OUT Z7RSDST 167 RB_P IN Z7LVRXIO
28 BG3_M OUT Z7RSDST 168 RC_M IN Z7LVRXIO
29 BG3_P OUT Z7RSDST 169 RC_P IN Z7LVRXIO
30 VDDSAVCC4 3.3V Z7RSTAVCC4 170 VDDAVDD1L 3.3V Z7LVRAVDD1L
31 VSSDGND1 GND Z7RSTDGND1 171 L_VDDPLL1 2.5V Z7LVRVDDPLL1
32 VDDCDVCC1 1.5V Z7RSTDVCC1 172 L_VSSPLL1 GND Z7LVRVSSPLL1
33 VSSAGND45C GND Z7RSTAGND45C 173 L_VDDPLL2 2.5V Z7LVRVDDPLL2
34 VDDSAVCC5 3.3V Z7RSTAVCC5 174 L_VSSPLL2 GND Z7LVRVSSPLL2
35 BB0_M OUT Z7RSDST 175 L_VDDD 1.5V Z7LVRVDDD
36 BB0_P OUT Z7RSDST 176 L_VSSD GND Z7LVRVSSD
37 BB1_M OUT Z7RSDST 177 PVDDA1B 2.5V Z7LVRVDDPLL1*1
38 BB1_P OUT Z7RSDST 178 PVDDA2B 2.5V Z7LVRVDDPLL2*1
39 BB2_M OUT Z7RSDST 179 VDDS_L 3.3V Z7LVRVDDS
40 BB2_P OUT Z7RSDST 180 PVSSA1B GND Z7LVRVSSPLL1*1
41 BB3_M OUT Z7RSDST 181 PVSSA2B GND Z7LVRVSSPLL2*1
42 BB3_P OUT Z7RSDST 182 VDDC_L 1.5V Z7LVRVDDC
43 VDDCLCDVDDC 1.5V Z7RSTVDDC 183 VDDAVDD2 2.5V Z7LVRAVDD2
44 VSSLCDVSS2 GND Z7RSTVSS2 184 VSSAGND2 GND Z7LVRAGND2
45 VSSAGND45R GND Z7RSTAGND45R 185 VDDAVDD1R 3.3V Z7LVRAVDD1R
To Next Page
