PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC32D44E/S/RU-BK/GY (1st Eddition)
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
(NOTE: THE PARTS HERE
SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKE266FM01(KEY Unit)
[4] DUNTKE449FM02 (MAIN Unit)
[5] DUNTKE457FM02 (R/C, LED Unit)
[6] DUNTKE491FM01(MINI-AV Unit)
[7] CABINET PARTS
[8] LCD MODULE ASSEMBLY
[9] SUPPLIED ACCESSORIES
[10] PACKING PARTS
[11] SERVICE JIGS
CONTENTS
No. S38F8LC32D44E
LCD COLOUR TELEVISION
MODELS
LC-32D44E/S/RU-BK/GY
