9. IC3001 (RH-IXC354WJZZQ)
The VCT-Pro front-end video processing unit offers 16 analog video inputs (CVBS/Y/C, RGB/Y Cr Cb) as well as digital interfaces for SDTV and DTV.
Latest 3D+ comb filter generation provides highest performance for PAL/NTSC signals.
A VBI slicer, supporting up to 2000 pages of Teletext completes the analog video front end. 3D-motion-adaptive de-interlacing, temporal noise reduc-
tion and film mode detection are based on a unified memory technology.
Description:
• Stereo Decoder Audio Processing.
• Video Front-end 3D Comb filter, PC Connectivity.
• Motion Adaptive De-interlacing.
• Scaling, Display Processing and FPD Control.
• Unified Memory for Audio, Video and Text.
• Controlling, OSD and Text.
Pin No. Pin Name I/O Pin Function
1 P4_6 O TP3008
2 P4_5 O HDMI_WPO Write-protection of HDMI_EEP.
3 P4_4 O HDMI_RSTO HDMI reset.
4 TCLK I JTAG Interface Clock Input (TV Controller)
5 TDO O JTAG Interface Data Output (TV Controller)
6 TDI I JTAG Interface Data Input (TV Controller)
7 TMS I JTAG Interface Mode Select Input (TV Contr.)
8 RESETQ I/O Reset Input/Output.
9 AIN1R I Analog Audio 1 Input, Right.
10 AIN1L I Analog Audio 1 Input, Left.
11 AIN2R I Analog Audio 2 Input, Right.
12 AIN2L I Analog Audio 2 Input, Left.
13 AIN3R I Analog Audio 3 Input, Right.
14 AIN3L I Analog Audio 3 Input, Left.
15 AIN4R I Analog Audio 4 Input, Right.
16 AIN4L I Analog Audio 4 Input, Left.
17 VREFAU --- Reference Voltage, Audio.
18 VSUP8.0AU --- Supply Voltage Analog Audio, 8.0 V.
19 GNDA --- Ground Analog Audio, Platform Ground.
20 SGND --- Analog Signal GND.
21 AOUT2R O Analog Audio 2 Output, Right.
22 AOUT2L O Analog Audio 2 Output, Left.
23 AOUT1R O Analog Audio 1 Output, Right.
24 AOUT1L O Analog Audio 1 Output, Left.
25 HEADPHONER O Analog Headphone Output, Right.
26 HEADPHONEL O Analog Headphone Output, Left.
27 SPEAKERR O Analog Loudspeaker Output, Right.
28 SPEAKERL O Analog Loudspeaker Output, Left.
29 SUBWOOFER TEST I/O TP3001
30 VREFSIF I Reference Voltage, Audio SIF.
31 SIFIN+ I Differential Sound IF Input.
32 SIFIN- I Differential Sound IF Input.
33 VSUP5.0 --- Supply Voltage Analog, 5.0 V.
34 GNDA --- Ground Analog, Platform Ground.
35 GND3.3DIG --- Ground Digital Interfaces.
36 VSUP3.3DIG --- Supply Voltage Digital Interfaces, 3.3 V.
37 SPDIF_OUT O SPDIF Output.
38 I2S_DA_IN I Audio Bus Data Input.
39 I2S_CL I Audio Bus Clock Input.
40 I2S_WS I Audio Bus Word Strobe Input.
41 I2S_DEL_OUT O TP3037
42 I2S_DEL_IN I TP3038
43 I2S_DEL_CL I/O TP3039
44 I2S_DEL_WS I/O TP3040
45 VSUP3.3RAM --- Supply Voltage Ram, 3.3 V.
46 GND3.3RAM --- Ground Ram.
47 DVS I Digital or Analog Video VSYNC HD Input.
48 DEN I Digital Video Enable Input.
49 DCLK I Digital Video Clock Input.
50 DRI7 I Digital Video Red 7 Input.
