LC32D44E/S/RU-BK/GY (1st Eddition)
1 – 1
LC32D44E-BK
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item
32" LCD COLOUR TV
LCD panel
32" Advanced Super View & BLACK TFT LCD
Resolution
1,049,088 pixels (1,366 x 768)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
TV-Standard Analogue CCIR (B/G, I, D/K, L, L’)
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF E2-E69ch, F2-F10ch, I21-I69ch, IR A-IR Jch, (Digital: E5-E69ch)
CATV Hyper-band, S1-S41ch
TV-Tuning System Auto Preset 99 ch, Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Brightness 450 cd/m2
Viewing angles H : 176° V : 176°
Audio amplifier
10W x 2
Speaker
(100mmx35mm)x2
Terminals Antenna
UHF/VHF 75Ω Din type (Analogue & Digital)
RS-232C 9 pin mini D-sub
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 SCART (AV input/output, Y/C input, RGB input, AV Link)
EXT 3 S-VIDEO (Y/C input), RCA pin (AV input)
EXT 4 Ø 3.5 mm jack (Audio input), 15 pin mini D-sub (PC)
EXT 5 Audio in, Component in
EXT 6 HDMI, Ø 3.5 mm jack (Audio input)
EXT 7 HDMI
C. I. (Common Interface) EN50221, R206001
OUTPUT RCA pin (Audio)
Headphones Ø 3.5 mm jack (Audio output)
OSD language English/German/French/Italian/Spanish/Dutch/Swedish/Portuguese/Finnish/Turkish/Greek/
Russian/Polish
Power Requirement AC 220-240 V, 50 Hz
Power Consumption 120 W (0.9 W Standby) (Method IEC60107)
Weight 11.0 kg (Display only), 13.0 kg (Display with stand)
Operating temperature
0°Cto+40°C
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
NOTE
• Refer to inside back cover for dimensional drawings.
Optional accessory
The listed optional accessories are available for the
LCD colour TV. Please purchase them at your nearest
shop.
• Additional optional accessories may be available in near
future. When purchasing, please read the newest catalogue
for compatibility and check the availability.
Part name Part number
Wall mount bracket
(LC-32D44E, LC-32D44S)
AN-37AG5
