Sharp LC-32D44E User Manual

LC32D44E/S/RU-BK/GY (1st Eddition)
21
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] CABINET PARTS
1 CCABAB985WJ01 BG N P Front Cabinet Ass'y (LC-32D44E(BK))
1 CCABAB985WJ02 BM N P Front Cabinet Ass'y (LC-32D44E(GY))
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - LED Cover
1-3 Not Available - N - Center Dec.
1-4 Not Available - N - SP Sheet
1-5 Not Available - - Mask Himelon, x2 (Top/Bottom)
1-6 Not Available - - Mask Himelon, x2 (Side)
1-7 XEBS930P08000 AA J Screw, x3 (Center Dec.)
2 CCABBB241WJ01 BE N P Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - N - Terminal Label
2-3 Not Available - N - VESA Holder, x4
2-4 Not Available - N - Molt Plane, x2
2-6 Not Available - N - Himelon, x5
2-7 XEBS930P08000 AA J Screw, x4 (VESA Holder)
3 CCOVAC614WJ01 AM N P MINI AV Cover Ass'y
3-1 Not Available - N - MINI AV Cover
3-2 Not Available - N - Himelon
4 R1LK315T3GW30Y N J 32" LCD Panel Module
5 GCOVAC612WJ1A AH N P Bottom Cover
6 GCOVAC637WJ1A AD N P PC Card Cover
7 JBTN-A718WJ1A AE N P Control Button
8 LANGKB350WJFW AS N P Center Angle (R)
9 LANGKB351WJFW AR N P Center Angle (L)
10 LANGKB358WJFW AW N P Bottom Angle
11 LANGKB359WJFW AD N P LCD Angle A, x2
12 LANGKB397WJFW AD N P LCD Angle B, x2
13 LHLDF1057CEZZ AB J Card Spacer
14 LHLDW1033CE00 AA J Wire Holder
15 LHLDWA143WJKZ AC J Wire Holder, x2 (Cable)
16 LHLDZA933WJKZ AB J MAIN PWB Hplder
17 LHLDZA934WJKZ AB N J POWER PWB Holder
18 PSLDMA403WJZZ AE J Spacer (10*45H), x2
19 P
SLDMB358WJFW AK N P Shield
20 PZETKA383WJKZ AG N P Barrier Sheet
21 QCNW-G658WJQZ AG P Connecting Cord (SP)
22 QCNW-G660WJQZ AE N P Connecting Cord (KM)
23 QCNW-G662WJQZ AF N P Connecting Cord (RA)
24 QCNW-G664WJQZ AK N P Connecting Cord (LA)
25 QCNW-G666WJQZ AG N P Connecting Cord (LB)
26 QCNW-H025WJQZ AM J LCD FFC, x2
27 RCORFA064WJZZ AF P Core, x2 (LCD FFC)
28 RSP-ZA321WJZZ AT N J Speaker (L)
29 RSP-ZA322WJZZ AT N J Speaker (R)
!
30 RTUDAA019WJQZ BA N P Tuner
31 TLABNC117WJZZ AB P Model Label
33 XBBS730P04000 AA J Screw (SHIELD)
34 XEBS930P08000 AA J Screw, x2 (TERMINALl)
35 XEBS940P16000 AB J Screw, x6 (CAB-B FIX)
36 XEBSN40P10000 AB J Screw, x6 (LCD-ANG FIX)
37 XHPS730P16WS0 AB N J Screw, x4 (MAIN ETC)
38 XHPS830P06WS0 AA N J Screw,x26 (PWB ETC)
39 XHPS830P10WS0 AB N J Screw,x3 (CAB-B FIX)
40 CDAi-A441WJ02 BF N J Stand Ass'y (LC-32D44E(BK))
40 CDAi-A441WJ05 BG N P Stand Ass'y (LC-32D44E(GY))
