LC32D44E/S/RU-BK/GY (1st Eddition)
5 – 12
179 VIN13 I Analog Video 13 B HD Input.
180 VIN12 I Analog Video 12 G HD Input.
181 VIN11 I Analog Video 11 R HD Input.
182 VIN9 I Analog Video 9 Y or B SD Input.
183 VIN8 I Analog Video 8 C or Fast Blank 1 Input.
184 VIN7 I Analog Video 7 Y or G SD Input.
185 VSUP1.8FE --- Supply Voltage Analog Video Frontend, 1.8 V.
186 GNDA --- Analog Video Frontend, Platform Ground.
187 VIN6 I Analog Video 6 C or R SD Input.
188 VIN5 I Analog Video 5 Y/CVBS Input.
189 VIN3 I Analog Video 3 CVBS Input.
190 VIN2 I Analog Video 2 CVBS Input.
191 VIN1 I Analog Video 1 CVBS Input.
192 VSUP3.3VO --- Supply Voltage Analog Video Output, 3.3 V.
193 VOUT3 O TP3002
194 VOUT2 O Analog CVBS Video 2 Output.
195 VOUT1 O Analog CVBS Video 1 Output.
196 GND3.3IO3 --- Ground Digital Input/Output Port 1.
197 VSUP3.3IO3 --- Supply Voltage Input/Output Port 1, 3.3 V.
198 656I0 P3_0 I DTM_IRQI Interrupt from DTV.
199 656I1 P3_1 I/O AVLINK_1
200 656I2 P3_2 I/O AVLINK_2
201 656I3 P3_3 I/O HDMI_INT_I Interrupt from receiver.
202 656I4 P3_4 I/O HDMI_INT_I Interrupt from receiver.
203 656I5 P3_5 O HOTP_CONT0 HDMI plug detection.
204 656I6 P3_6 I MIC_IREQ Interrupt from microcomputer.
205 656I7 P3_7 O HOTP_CONT1 HDMI plug detection.
206 656CLKI I N.C.
207 656CLKO O N.C.
208 P4_7 I HP_PLG Headphone detection.
Pin No. Pin Name I/O Pin Function
