LC-32D44U
4 – 1
LC-32D44U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the 4 lock screws and detach the Stand.
2. Remove the 3 lock screws, 6 lock screws, 1 lock screw and detach the Rear Cabinet.
2
2
2
1
Stand
Front Cabinet
Rear Cabinet
