LC-32D44U
1 – 1
LC-32D44U
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-32D44U
LCD panel
32" screen size class Advanced Super
View & BLACK TFT LCD
(Diagonal Measurement : 31
1
/
2
)
Resolution 1,049,088 pixels (1,366 768)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 AV in, S-VIDEO in
INPUT 3 COMPONENT in
INPUT 4 HDMI in with HDCP
INPUT 5 Audio in, HDMI in with HDCP
INPUT 6 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
SERVICE Software update
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
Power Consumption 135 W (0.3 W Standby with AC 120V)
Weight
TV + stand 29.8 lbs./13.5 kg
TV only 25.4 lbs./11.5 kg
Dimension
*2
(W H D)
TV + stand 30
9
/
16
22
41
/
64
9
1
/
16
inch
TV only 30
9
/
16
20
19
/
32
3
45
/
64
inch
Operating temperature 32°F to 104°F (0°C to 40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the Spanish operation manual.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
"
++ +
To Next Page
