Sharp LC-32D44U User Manual

LC-32D44U
5 – 7
6 [HDTV]
1 COMP33K ADJ (INPUT1) Component 33K picture level adjustment (main)
2 COMP33K ADJ (INPUT3)
3 COMP33K Y A_GAIN
4 COMP33K Cb A_GAIN
5 COMP33K Cr A_GAIN
6 COMP33K Y D_GAIN
7 COMP33K Cb D_GAIN
8 COMP33K Cr D_GAIN
9 COMP33K Y OFFSET Y OFFSET adjustment value
10 COMP33K Cb OFFSET Cb OFFSET adjustment value
11 COMP33K Cr OFFSET Cr OFFSET adjustment value
7 [ANALOG RGB]
1 ANALOG RGB ADJ Analog RGB picture level adjustment
2 R A-GAIN
3 G A-GAIN
4 B A-GAIN
5 R D-GAIN
6 G D-GAIN
7 B D-GAIN
8R OFFSET
9 G OFFSET
10 B OFFSET
8 [M GAMMA IN]
1 LEV1 Standard value 1 Adjustment gradation setting.
2 LEV2 Standard value 2
3 LEV3 Standard value 3
4 LEV4 Standard value 4
5 LEV5 Standard value 5
6 LEV6 Standard value 6
9 [M GAMMA R1]
1 MG1R WB adjustment Point 1, R adjustment value Parameter for six-point adjustment
2 MG1G WB adjustment Point 1, G adjustment value
3 MG1B WB adjustment Point 1, B adjustment value
4 MG2R WB adjustment Point 2, R adjustment value
5 MG2G WB adjustment Point 2, G adjustment value
6 MG2B WB adjustment Point 2, B adjustment value
7 MG3R WB adjustment Point 3, R adjustment value
8 MG3G WB adjustment Point 3, G adjustment value
9 MG3B WB adjustment Point 3, B adjustment value
10 [M GAMMA R4]
1 MG4R WB adjustment Point 4, R adjustment value Parameter for six-point adjustment
2 MG4G WB adjustment Point 4, G adjustment value
3 MG4B WB adjustment Point 4, B adjustment value
4 MG5R WB adjustment Point 5, R adjustment value
5 MG5G WB adjustment Point 5, G adjustment value
6 MG5B WB adjustment Point 5, B adjustment value
7 MG6R WB adjustment Point 6, R adjustment value
8 MG6G WB adjustment Point 6, G adjustment value
9 MG6B WB adjustment Point 6, B adjustment value
11 [SOUND 1]
1 Audio Switch
2 Flat Mode
3 ADC Volume 1
4 ADC Volume 2
5 ADC Volume 3
6 ADC Volume 4
7 ADC Volume 5
8 ADC Volume 6
Page Line Item Description Remarks (adjustment detail, etc.)
