LC-32D44U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE264FM02 AP X R/C, LED Unit
N DUNTKE266FM02 AG X KEY Unit
N DUNTKE450FM01 CF N R MAIN Unit
N RUNTKA397WJQZ BT N X POWER/INVERTER Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
N R1LK315T3GW20Z DC N J 32" Wide LCD Panel Module Unit
[3] DUNTKE264FM02 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor, 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode, UDZSNPTE-1712B
D103 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D114 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
D115 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
IC101 VHIGA1S100W-1Y AE J IC, GA1A1S100WP
P101 QPLGNA335WJZZY AD J Plug, 15pin (RA)
Q102 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q103 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q104 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q106 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q107 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor, 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Control
SLD101 PSLDPA076WJFW AD J Shield Case
[4] DUNTKE266FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug, 5pin (KM)
R151 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH-UP
S152 QSW-K0003AJZZ+ AB J Switch, CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch, INPUT
S154 QSW-K0003AJZZ+ AB J Switch, VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL-DOWN
S156 QSW-K0003AJZZ+ AB J Switch, MENU
S157 QSW-K0003AJZZ+ AB J Switch, POWER
[5] DUNTKE450FM01 (MAIN Unit)
C501 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C503 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C504 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C505 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C506 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C507 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C508 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C509 VCCCCZ1HH220JY AB J Capacitor, 22p 50V Ceramic
C510 VCCCCZ1HH560JY AB J Capacitor, 56p 50V Ceramic
C512 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C513 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C514 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C515 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C516 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C517 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C518 VCCCCZ1HH3R0CY AA J Capacitor, 3p 50V Ceramic
C519 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C520 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C521 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C522 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C523 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C524 VCCCCZ1HH560JY AB J Capacitor, 56p 50V Ceramic
C525 VCCCCZ1HH120JY AB J Capacitor, 12p 50V Ceramic
C526 VCCCCZ1HH560JY AB J Capacitor, 56p 50V Ceramic
C527 VCCCCZ1HH560JY AB J Capacitor, 56p 50V Ceramic
C528 VCCCCZ1HH560JY AB J Capacitor, 56p 50V Ceramic
C529 VCCCCZ1HH270JY AB J Capacitor, 27p 50V Ceramic
