Pin information STV0360
8/66 STMicroelectronics Confidential 7283434C
Confidential
Front end controls
16 AGC1 IO RF AGC control
Σ∆ 4
14 AGC2 IO IF AGC control
Σ∆ 4
17, 60 TEST Reserved test mode, must be grounded
58 IP0 I General-purpose input port 0 and ADC input for
RF level monitoring
-
45 OP0 IO General-purpose output port 0 4
43 LOCK/OP1 IO General-purpose output port 1 or lock indicator 4
42 LOCK/OP2 O General-purpose output port 2 or lock indicator 4
47 AUX_CLK IO Auxiliary clock 8
55 CS0 I Chip select LSB -
53 CS1 I Chip select MSB -
Power supply
13, 28, 39, 57 VDD Supply Digital core supply
22, 35, 44, 52 VDD_3.3 Supply Digital IO supply
15, 24, 30, 37,
41, 46, 54, 56,
59
GND Ground
1. All inputs are 3.3 V compatible
2. All bidirectional pads are 3.3 V capable
3. All outputs are 3.3 V capable
Table 1: STV0360 pin description
Pin number Name Type Description Drive (mA)
