LC-32HT1U
TV (rear view)
Setting the TV
Preparation
Connect the AC plug for the TV into the power outlet.
1
3
Remove the terminal covers on the rear of the TV.
Place the ferrite core in the space indicated in the below figure and bundle the cords
properly with a cable clamp and cable tie.
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.
Press down the upper hooks to
remove the covers toward you.
2
Attach your antenna to the back of the TV.
4
To power outlet
NOTE
• The TV can be swiveled 10 degrees right and left with TV stand attached.
• You cannot tilt the screen vertically.
AC cord
Preparation
!
"#"
!
"#"
$
%
& "
' (
$ %
$
%
)* )(
$
%
Cable without a CATV
converter
Combination
VHF/UHF antenna
Separate VHF/UHF
antenna
Connecting Antenna Cable
+, " )$) ) *$ !$(
)$
) $ %,
-, " )$) ) ./
* '
( $ %,
!$(
!$(
When connecting the RF cable to the TV set, do not tighten
F-type connector with tools.
If tools are used, it may cause damage to your TV set.
(The breaking of internal circuit, etc.)
F-type connector should be finger-tightened only.
NOTICE
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector ,
plug it into the antenna terminal at the rear of the TV set.
Connecting to the PPV terminal box
Connect the TV and the PPV terminal box as shown.
RJ-11 cable (supplied by Pay Per View provider)
Coaxial cable
(commercially available)
To power outlet
To room antenna terminal
PPV terminal box
Hotel server
Connection for
a clear digital signal
Signal splitter
(commercially available)
