Sharp LC-37DB5U Service Manual

22
LC-37DB5U
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE
RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKD331FE16 J DIGITAL Unit CG
DUNTKD352WE03 R AV Unit CB
DUNTKD353WE01 R KEY Unit AK
DUNTKD354WE01 R R/C, LED Unit AN
DUNTKD376FM07 R MAIN Unit CB
RDENCA140WJQZ X POWER Unit BX
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCUCA026WJZZ J 37 WIDE LCD PANEL MODULE Unit ER
DUNTKD331FE16
DIGITAL UNIT
RESISTORS
R8106 VRS-CZ1JF470JY J 47 1/16W Metal Oxide AA
R8107 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R8125 VRS-CH1JF470JY J 47 1/16W Metal Oxide AA
R8164 VRS-CZ1JF470JY J 47 1/16W Metal Oxide AA
R8198 VRS-CZ1JF470JY J 47 1/16W Metal Oxide AA
R8208 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R8209 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R9537 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
R9538 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
R9539 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
DUNTKD352WE03
AV UNIT
DIODE
D103 RH-PXA089WJZZY R PhotoDiode AC
RESISTOR
R108 VRS-CY1JF561JY R 560 1/16W Metal Oxide AA
RESISTORS
R3926 VRS-CY1JF102JY R 1k 1/16W Metal Oxide AA
R3930 VRS-CY1JF102JY R 1k 1/16W Metal Oxide AA
DUNTKD354WE01
R/C, LED UNIT
