23
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-37DB5U
42 PMLT-A261WJZZ X Gasket (10x5.5x15) AC
44 PMLT-A263WJZZ X Gasket (20x50x45) AM
45 PRDARA191WJFW X Heat Sink (For IC2502) AE
46 PRDARA192WJFW X Heat Sink (For IC3800) AE
47 PRDARA216WJFW X Heat Sink (For IC2502) AF
48 PSLDMA651WJZZ X Shield (70x20(E05G)) AH
49 PSLDMA693WJZZ X Shield (15x20(E02)) AD
50 PSLDMA704WJZZ X Shield (30x50(E02)) AF
51 PSLDMA777WJZZ X MAIN Shield A AM
52 PSLDMA778WJZZ X MAIN Shield B AM
53 PSLDMA779WJFW X MAIN Shield C AK
54 PSLDMA835WJFW X LCD-CTRL-Shield AK
55 PSLDMA848WJZZ X Shield (15x20(E05G)) AD
56 PSLDMA850WJZZ X Shield, x2 (40x15(E02)) AE
58 PSPAZA635WJKZ X Heat Sink (For IC2502) AD
59 PSPAZA636WJKZ X Heat Sink (For IC3800) AD
60 PSPAZA646WJKZ X Heat Sink (For IC8601) AD
61 PSPAZA660WJKZ X Heat Sink (For IC9606) AD
62 PSPAZA663WJKZ X Heat Sink, x2 (For IC2502) AE
63 PSPAZA818WJKZ X Heat Sink (For SC9401) AH
64 PSPAZA917WJKZ X Heat Sink (For IC8101) AK
65 QCNW-D080WJQZ X Connectiong Cord (DA/DS) AU
68 QCNW-D306WJQZ X Connectiong Cord (SP) AL
69 QCNW-D308WJQZ X Connectiong Cord AL
(RA:AV-LED)
70 QCNW-D766WJQZ X Connectiong Cord (FC) AG
71 QCNW-D769WJQZ X Connectiong Cord AH
(MAIN-CONT)
72 QCNW-D773WJQZ X Connectiong Cord (P3203) AH
73 QCNW-D775WJQZ X Connectiong Cord BB
(MAIN-CONT)
74 QCNW-D777WJQZ X Connectiong Cord (KM) AH
75 QCNW-D780WJQZ X Connectiong Cord
(POW-INV)
AH
76 QCNW-D781WJQZ X Connectiong Cord (PA) AL
77 QCNW-D783WJQZ X Connectiong Cord
(POW-INV)
AL
78 QCNW-D821WJQZ X Connectiong Cord (DP) AG
79 QCNW-D822WJQZ X Connectiong Cord (PE,PD) AN
81 QEARPA172WJFW X Earth Spring C AC
83 RSP-ZA106WJZZ X Speaker (L) AX
84 RSP-ZA107WJZZ X Speaker (R) AX
85 XBBS740P06000 X Screw, x7 AA
(FOR CENTER ANG)
86 XBBS930P06000 X Screw, x13 (AC-ANG HDMI) AA
87 XBBS940P10000 X Screw, x1
(FOR Stand-Cover)
AB
88 XBBSN50P12JS0 X Screw, x4 (FOR Stand) AB
89 XBPS730P06WS0 X Screw, x28 AB
(Screw FOR PWB)
92 XEBS930P08000 X Screw, x7 (FOR Terminal) AA
93 XEBS940P16000 X Screw, x19 (CAB-B) AA
94 XEBSN30P10000 X Screw, x11 AA
95
Not Availabl
e – No.Label —
96 LHLDWA044WJKZ X Wire Holder AB
97 LX-NZ3047GEZZ X Tuner Nut AB
98 PMLT-A198WJZZ X Gasket AC
99 PMLT-A243WJZZ X Gasket AF
100 PMLT-A264WJZZ X Gasket AM
101 PMLT-A266WJZZ X Gasket AD
102 PSLDMA519WJZZ X Shield AC
103 PSLDMA866WJZZ X Shield AG
104 QCNCWA496WJZZ X F-RCA Connector AK
105 QCNW-D629WJPZ X Connectiong Cord (Tuner) AH
106 QEARPA176WJZZ X Earth Spring AH
107 QEARZA090WJZZ X Gasket, x2 AD
1 CCABAB083WJ01 X Front Cabinet Ass'y BQ
1-1
Not Available
– Front Cabinet —
1-2
Not Available
– Badge, SHARP —
1-3 PSPAHA412WJZZ X Mask Spacer, x2 AD
1-4 PSPAHA416WJZZ X Mask Spacer, x2 AC
1-5 TLABZB031WJSA X HDTV Label AD
2 CCABBA544WJ03 X Rear Cabinet Ass'y BR
2-1
Not Available
– Rear Cabinet —
2-2 HiNDPB427WJSA X AV Jack indicator A AM
2-3 HiNDPB369WJSA X AV Jack indicator B AH
2-4 LHLDWA055WJKZ X Wire Holder, x2 AC
2-5 LHLDWA057WJKZ X Wire Holder AE
3 CCOVAB143WJ01 X Top Control Cover Ass'y AS
3-1
Not Available
– Top Control Cover —
3-2 JBTN-A428WJKA X Operation Button AF
3-3 JBTN-A429WJKA X Power Button AD
3-4 MSPRCA049WJFW X Spring for Power Button AD
4 CDAi-A195WEV1 X Stand Ass'y BS
4-1 CANGTA181WJSA X Stand Bracket Ass'y BD
4-1-1 GDAi-A197WJSB X Stand Support
4-1-2 LANGTA181WJSA X Stand Bracket
4-2 CDAi-A195WJKB X Stand Base Ass'y BP
4-2-1
Not Available
– Stand Base —
4-2-2 LANGKA443WJSA X Base Bracket
4-2-3 PSPAZA476WJZZ X LEG-Cushion-B, x2
4-2-4 PSPAZA477WJZZ X LEG-Cushion-C, x4
4-2-5 PSPAZA617WJZZ X LEG-Cushion-A, x2
4-3 XCSSN50P25000 X Screw, x5 (Stand Base) AB
6 CCOVAB174WJ01 X Terminal Cover Ass'y BB
6-1
Not Available
– Terminal Cover —
6-2 PSPAHA413WJZZ X HIMERON, x15 AB
7 RLCUCA026WJZZ J
37 WIDE LCD PANEL MODULE Unit
ER
8 DUNTKD331FE16 J DIGITAL Unit CG
9 DUNTKD352WE03 R AV Unit CB
10 DUNTKD353WE01 R KEY Unit AK
11 DUNTKD354WE01 R R/C, LED Unit AN
12 DUNTKD376FM07 R MAIN Unit CB
13 RDENCA140WJQZ X POWER Unit BX
14 NSFTZ0134CEFW X Shaft, x2 (RS232C)
15 PSLDMA602WJFW X HDMI-Shield (Bottom)
16 PSLDMA865WJFW X HDMI-Shield (Top)
18 GCOVAB189WJKB X Jack Cover A AL
19 GCOVAB111WJKA X Bracket Cover AP
20 GCOVAB348WJKA X Jack Cover B AG
21 GCOVAB190WJKB X Jack Cover C AH
22 GCOVAA678WJKA X SD Cover AG
23 HDECQA346WJSA X LED Decoration AE
24 HiNDPB384WJSA X Model Label AH
25 LANGTA198WJZZ X Center Angle BD
26 LHLDW1060CEZZ X Wire Holder, x2
(DIGI SHLD)
AB
28 LHLDWA058WJKZ X MAIN Shield AC
29 LHLDWA080WJKZ X Wire Holder AB
30 LHLDWA096WJKZ X Edge Saddle AD
31 LHLDWA113WJQZ X Wire Holder AF
32 NSFTZA144WJFN X Shaft AD
33 PCLiCA004WJKZ X Rivet AC
34 PCOVUA080WJZZ X LED Shading Cover AD
35 PMLT-A146WJZZ X Gasket (10x2x40) AD
36 PMLT-A158WJZZ X Gasket (10x2x10) AC
37 PMLT-A240WJZZ X Gasket (25x10x190) AM
39 PMLT-A255WJZZ X Gasket (10x2x60) AD
40 PMLT-A256WJZZ X Gasket, x3 (10x5.5x100) AF
CABINET AND MECHANICAL PARTS
To Next Page
