Part names
TV (Front)
TV (Rear)
POWER indicator**
OPC sensor*
POWER (On/Off)
button
INPUT
button
Volume buttons (VOL / )
Channel buttons
(CH / )
Remote control sensor OPC indicator*
RESET*
INPUT 3
terminals
SYSTEM
RESET**
DIGITAL AUDIO
OUTPUT
* Press RESET if the TV cannot return to its original state after performing various operations.
AV MODE resets to DYNAMIC (Fixed)
TV channel returns to initial channel setting (Air: 2ch, Cable:1 or 2ch)
Audio setting initializes
Surround resets to Off
Image position initializes
** Press SYSTEM RESET if the TV does not operate after starting up.
NOTE
Pressing RESET will not work if the TV is in standby mode.
Pressing RESET will not delete channel preset or secret number.
AC INPUT terminal
RS-232C
terminal
INPUT 2 terminals
INPUT 1
terminals
INPUT 4
terminals
MONITOR OUTPUT terminals
Antenna input terminal
(ANALOG)
Antenna input
terminal (DIGIT
AL)
