Sharp LC-37DB5U Service Manual

6
LC-37DB5U
SPECIFICATIONS
Item 37" LIQUID CRYSTAL TELEVISION,
Model: LC-37DB5U
TV
Function
American TV Standard ATSC/NTSC System
VHF/UHF
VHF 2-13ch, UHF 14-69ch
CATV 1-125ch
Audio multiplex BTSC System
Terminals AV in, COMPONENT in
INPUT 2
AV in, COMPONENT in
INPUT 4 Audio in, HDMI in with HDCP
INPUT 3
S-VIDEO in, AV in
OSD language English/French/Spanish
Power Requirement
AC 120 V, 60 Hz (FOR NORTH AMERICA)
AC 110-240 V, 50/60 Hz(FOR OTHERS)
Power Consumption
Weight
Accessories Operation manual ( 1), Remote control unit ( 1), AC cord ( 1), "AAA" size
battery ( 2), Cable clamp ( 1), Cable tie ( 1)
TV-standard (CCIR)
Receiving
Channel
Rear INPUT 1
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
LCD panel 37" Advanced Super View & BLACK TFT LCD
Number of dots 3,147,264 dots (1366 768 3 dots)
Brightness 450 cd/m
2
Backlight 60,000 hours (at Backlight Standard position)
Viewing angles H : 170
O
V : 170
O
Audio out 10W 2
MONITOR OUTPUT S-VIDEO out, AV out
188 W
ANALOG ANTENNA 75 Unbalance, F Type for VHF/UHF/CATV in 1
DIGITAL ANTENNA 75 Unbalance, F Type for Digital Air in 1
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
45.2 lbs./20.5 kg (w/o stand)
56.2 lbs./25.5 kg (with stand)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Dimension (W H D)
43
1
/2 22
1
/8 4
31
/64 inch (w/o stand),
43
1
/2 25
15
/32 12
3
/64 inch (with stand)
Operating temperature
32
O
F to 104
O
F (0
O
C to 40
O
C)
××
×
×
×
×
×
××
×
×××
×××
××
Ω
Ω
++
+

Sharp LC-37DB5U Specifications

General

Brand	Sharp
Model	LC-37DB5U
Category	LCD TV
Language	English
