Sharp LC-37DB5U Service Manual

14
LC-37DB5U
REMOVING OF MAJOR PARTS
1. Remove the Terminal Cover 1.
2. Remove the 1 lock screw 2 and detach the Bracket Cover.
3. Remove the 4 lock screws 3 and detach the Stand.
4. Remove the Rear Cabinet.
Remove the 19 lock screws 4, 9 lock screws 5, 7 lock screws 6 and detach the Rear Cabinet.
2
4
1
3
6
5
5
Stand
Terminal Cover
Bracket
Cover
Rear
Cabinet
5
