LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 1
LC32X20E
Service Manual
CHAPTER 2. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS (LC-32X20E/S/RU)
1. Remove the 3 lock screws , 4 lock screws , 2 lock screws and the 9 lock screws . Detach the Rear Cabinet.
1
2
3
4
SHEET FOR BOSS
4
1
3
2
REAR CABINET
