LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 11
[2] REMOVING OF MAJOR PARTS (LC-37X20E/S/RU)
1. Remove the 2 lock screws , 4 lock screws , 3 lock screws , 6 lock screws and the 4 lock screws . Detach the Rear Cabinet.
1
2
3
4 5
REAR CABINET
SHEET FOR BOSS
3
5
4
2
1
