Sharp LC-37X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
IC1503 RH-IXC287WJQZS AH J IC RGB (PC)_EXT7
IC1504 VHINJM2750M-1Y AH J IC NJM2750M(TE2)
IC1505 RH-IXC284WJQZS AL J IC HDMI_EXT4
IC1506 VHITC7W08U/-1Y AD J IC TC7W08FU(TE12L,F)
IC1507 VHISII9185+-1Q AP J IC SII9185CTU
IC1508 VHIAHC1G08W-1Y AD J IC 74AHC1G08GW/G,125
IC1805 VHIBH33FB1G-1Y AD J IC BH33FB1WG-TR
IC2001 VHIBD5224G+-1Y AD J IC BD5224G-TR
IC2002 RH-IXB986WJN8Q AW J IC Monitor Microcomputer
IC2004 VHIBR24L08F-1Y AE J IC BR24L08F-WE2
IC2006 VHITCVHC32T-1Y AE J IC TC74VHC32FT(EL)
IC2008 VHI7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC2009 VHILCX125FT-1Y AD J IC TC74LCX125FT(EL,K)
IC2010 VHITC7W00U/-1Y AE J IC TC7W00FU(TE12L,F)
IC2011 VHITC7W08U/-1Y AD J IC TC7W08FU(TE12L,F)
IC2401 VHI7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC2402 VHILCX157FT-1Y AD J IC TC74LCX157FT(EKJ)
IC2403 VHIISL83220-1Y AQ J IC ISL83220ECVZ-T
IC2601 VHITC7W66U/-1Y AE J IC TC7W66FU(TE12L,F)
IC2602 VHIM62332FP-1Y AL J IC M62332FPCF5J
IC3301 RH-IXC010WJQZQ BU J IC SVP-WX68(7568W-LF)
IC3501 RH-IXC163WJQZQ AZ J IC K4D263238-VC40
IC3502 RH-IXC163WJQZQ AZ J IC K4D263238-VC40
IC4401 VHILCX245FT-1Y AD J IC TC74LCX245FT(EKJ)
IC4402 VHILCX573FT-1Y AF J IC TC74LCX573FT(EKJ)
IC4403 VHITC7SH08U-1Y AF J IC TC7SH08FU(TE85L,JF)
IC4404 VHILCX244FT-1Y AE J IC TC74LCX244FT(EL,K)
IC4405 VHILCX573FT-1Y AF J IC TC74LCX573FT(EKJ)
IC4406 VHIAHC1G32W-1Y AD J IC 74AHC1G32GW,125
IC4408 VHIAHC1G02W-1Y AD J IC 74AHC1G02GW,125
IC8101 RH-IXC011WJQZQ BU J IC HiDTVPro-LX66(8166LF)
IC8301 RH-IXC154WJQZQ AZ J IC K4N56163QI-ZC2A
IC8302 RH-IXC154WJQZQ AZ J IC K4N56163QI-ZC2A
IC8303 RH-IXC154WJQZQ AZ J
IC K4N56163QI-ZC2A
IC8304 RH-IXC154WJQZQ AZ J IC K4N56163QI-ZC2A
IC8701 VHIS29GL128-1Q AZ J IC S29GL128N90TFIR20H
IC8702 RH-IXC150WJQZY AQ J IC ICS475GI-14LFT
IC8704 VHIS24CS64A-1Y AF J IC S-24CS64AOI-J8T1G
IC9101 RH-IXC121WJQZQ AX J IC XC95288XL-10TQG144C
IC9104 VHITCLCX08FT1Y AD J IC TC74LCX08FT(EL,K)
IC9105 VHI74VHC541-1Y AE J IC TC74VHC541FT(EKJ)
IC9106 VHI74VHC04T-1Y AD J IC TC74VHC04FT(EL,K)
IC9301 VHILTC1694C-1Y AM J IC LTC1694CS5#TRPBF
IC9601 VHITPS40055-1Y AN J IC TPS40055PWPR
IC9602 VHIMP2367DN-1Y AH J IC MP2367DN-LF-Z
IC9603 VHITPS40055-1Y AN J IC TPS40055PWPR
IC9604 VHITPS40055-1Y AN J IC TPS40055PWPR
IC9605 VHIPQ025ENA-1Y AE J IC PQ025ENA1ZPH
IC9606 VHITPS40055-1Y AN J IC TPS40055PWPR
J1501 QJAKJ0008GEZZ AD J Jack
J1502 QJAKJ0008GEZZ AD J Jack
L1103 VPSBN100J1R2NY AB J Coil Peaking 10µH
L1104 VPCNN120J1R9NY AB J Coil Peaking 12µH
L1105 VPCNN120J1R9NY AB J Coil Peaking 12µH
L1106 VPCNN120J1R9NY AB J Coil Peaking 12µH
L1501 RCILFA116WJZZY AE J Coil
L1502 RCILFA116WJZZY AE J Coil
L1503 RCILFA116WJZZY AE J Coil
L1504 RCILFA116WJZZY AE J Coil
L1506 RCILFA116WJZZY AE J Coil
L1507 RCILFA116WJZZY AE J Coil
L1508 RCILFA116WJZZY AE J Coil
L1509 RCILFA116WJZZY AE J Coil
L1510 RCILFA116WJZZY AE J Coil
L1511 RCILFA116WJZZY AE J
Coil
L1512 RCILFA116WJZZY AE J Coil
L1513 RCILFA116WJZZY AE J Coil
L2601 RCILFA154WJZZY AC J Coil
L2602 RCILFA154WJZZY AC J Coil
L2603 RCILFA154WJZZY AC J Coil
L2604 RCILFA154WJZZY AC J Coil
L2605 RCILFA154WJZZY AC J Coil
L2606 RCILFA154WJZZY AC J Coil
L2607 RCILFA154WJZZY AC J Coil
L2608 RCILFA154WJZZY AC J Coil
L2609 RCILFA154WJZZY AC J Coil
L2610 RCILFA154WJZZY AC J Coil
L2611 RCILFA154WJZZY AC J Coil
L2612 RCILFA154WJZZY AC J Coil
L3301 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L3302 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L3303 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L3304 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L3305 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
L3306 VPCWM2R2MR10NY AC J Coil Peaking 2.2µH
[3] DUNTKE237FM02 (MAIN Unit)
