Sharp LC-37X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
18
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
VA1511 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1512 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1513 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1514 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1515 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1516 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1517 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1518 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1519 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1520 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1521 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1522 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1523 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
VA1524 RH-VXA187WJQZY AB J Varistor EZAEG2A50AX
X2001 RCRSC0032TAZZY AG J Crystal, 32.768kHz
X3301 RCRSCA174WJQZY AG J Crystal
X8101 RCRSCA174WJQZY AG J Crystal
X8102 RCRSC0032TAZZY AG J Crystal, 32.768kHz
X8701 RCRSCA086WJZZY AG J Crystal 27MHz
N PSHEPA540WJZZ AD J Sheet
N QCNCMA225WJSA AY J Card Slot
N QCNWNA883AWPZ AD J Connecting Cord (DDR1 G_G)
N XBPSN20P14JS0 AB J Screw (Card Slot), x4
[4] DUNTKE238FM01 (TERMINAL Unit)
C401 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C402 VCCCCY1HH330JY AA J Capacitor 33p 50V Ceramic
C403 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C405 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C408 VCCCCY1HH221JY AA J Capacitor 220p 50V Ceramic
C411 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C414 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C417 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C420 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C422 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C423 RC-KZA178WJZZY AC J Capacitor 4.7 25V Ceramic
C424 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C426 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C428 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C429 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C430 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C431 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C432 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C433 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C501 VCERMZ1CN107MY AD J Capacitor 100 16V Electrolytic
C502 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C503 VCEASY1CN227MY AC J Capacitor 220 16V Electrolytic
C504 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C505 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C506 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C507 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C511 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C512 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C513 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C514 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C515 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C516 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C517 VCEASY1CN227MY AC J Capacitor 220 16V Electrolytic
C518 RC-KZA237WJZZY AB J
Capacitor 10 16V Ceramic
C519 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C524 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C525 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C528 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C531 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C532 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C533 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C534 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C535 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C536 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C537 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C538 VCKYCY1HB221KY AA J Capacitor 220p 50V Ceramic
C539 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C540 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C541 VCKYCY1HB331KY AA J Capacitor 330p 50V Ceramic
C542 VCKYCY1HB331KY AA J Capacitor 330p 50V Ceramic
C543 VCKYCY1HB331KY AA J Capacitor 330p 50V Ceramic
C544 VCKYCY1HB331KY AA J Capacitor 330p 50V Ceramic
C545 VCKYCY1HB471KY AA J Capacitor 470p 50V Ceramic
C546 VCKYCY1HB471KY AA J Capacitor 470p 50V Ceramic
C547 VCKYCY1HB471KY AA J Capacitor 470p 50V Ceramic
C548 VCKYCY1HB471KY AA J Capacitor 470p 50V Ceramic
C549 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C550 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C551 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C552 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
[3] DUNTKE237FM02 (MAIN Unit)
