Sharp LC-37X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
32
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] CABINET PARTS (LC-37X20E/S/RU)
1 CCABAB824WJ11 N P Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - - Front Cover Ass'y
1-3 HDECQA777WJ1A AC N J LED Cover
1-4 HPNLSA148WJ1A N P Speaker Net
1-5 Not Available - - Mask Himelon, x6
1-6 Not Available - - Front Cover tape, x6
1-7 XJPS730P08WS0 AA J Screw, x3 (Front Mask)
2 CCABBB128WJ11 N P Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 HINDPC570WJSA N P Terminal Label
3 CCOVAC335WE01 N P Key Cover Ass'y
3-1 Not Available - - Key Cover Ass'y
3-2 DUNTKE266FM01 AR N R KEY Unit
4 CDAI-A380WJ12 N P Stand Unit
5 CCOVAC334WE02 N P NINI AV Cover Ass'y
5-1 Not Available - - MINI AV Cover
5-2 Not Available - - MINI AV Angle
5-3 DUNTKE306FM01 N R MINI AV Unit
5-4 XJPS730P08WS0 AA J Screw, x2 (MINI AV Unit)
6 R1LK370D3LZ60Y N J 37" LCD Panel Module
7 DUNTKE237FM02 N R MAIN Unit
8 DUNTKE238FM01 N R TERMINAL Unit
9 DUNTKE264FM01 AS N R R/C, LED Unit
10 RDENCA230WJQZ N R Power Unit
11 GCOVAB586WJKA P PC Card Cover
12 GCOVAC337WJ1A N P Bottom Cover
13 LANGKB268WJFW AS N J Stand Angle
14 LANGKB301WJFW AL N J Stand Support Angle
16 LHLDW1173CEZZ AD J Wire Holder, x8
17 LHLDWA048WJKZ AB J Wire Holder
18 LHLDWA092WJZZ AB J Wire Holder, x2
19 LX-BZA170WJF9 P Screw, x2 (CAB-B)
20 LX-HZA003WJFN AC J
Screw, x2 (Speaker)
21 NSFTZA237WJFN AC N J Shaft, x4
22 PCOVP2610WJZZ AG J LCD Control Cover
23 PFLT-A072WJZZ P Felt, x2
24 PMLT-A255WJZZ AD J Molt Spacer, x3
25 PSHEPA543WJZZ P Sheet, x2 (for Boss)
26 PSLDMB198WJFW N P Main Shield
27 PSPAZB313WJKZ AC J Spacer (COOL_20*20_T2.0)
28 QCNW-G191WJQZ N P Connecting Cord (KM:MAIN-KEY)
29 QCNW-G202WJQZ N P Connecting Cord (RA:MAIN-LED)
30 QCNW-G203WJPZ N P Connecting Cord (US:MAIN-MINI-AV)
31 QCNW-G194WJQZ N P Connecting Cord (VD:TERMINAL-MINI_AV)
32 QCNW-G205WJQZ N p Connecting Cord (SP:TERMINAL-SP)
33 QCNW-G206WJQZ N P Connecting Cord (LA:POWER-INV)
34 QCNW-G207WJQZ N P Connecting Cord (LB:MAIN-POWER)
35 QCNW-G198WJQZ N P Connecting Cord (PL:POWER-LCDCTL)
36 QCNW-G199WJQZ N P Connecting Cord (LP:MAIN-LCD)
37 QCNW-G200WJQZ N P Connecting Cord (LW:MAIN-LCDCTL)
39 QEARPA273WJFW N P Earth Plate
40 RCORF0103CEZZ AK J Core (SP Wire)
41 RCORFA023WJZZ AK J Core (RA Wire)
42 RSP-ZA259WJZZ AZ N J Speaker (L)
43 RSP-ZA260WJZZ AZ N J Speaker (R)
45 TLABZB631WJZZ N P POP Label (LC-37X20E/S)
45 TLABZB632WJZZ N P POP Label (LC-37X20US)
46 TLABZB675WJZZ N P POP Label
47 XBBS830P06000 AA J Screw, x16 (TRAY,MINI-AV)
48 XBBS930P04000 AA J Screw, x5 (TUNER FIX_1/CNTL COV FIX_4)
49 XBPS730P06WS0 AA J Screw, x10 (STAND ANGLE)
50 XBPS830P06000 AA J Screw, x3 (HDMI)
51 XEBS930P08000 AA J Screw, x4 (TERMINAL)
52 XEBS940P16000 AB J Screw, x8 (CAB-B/BTM COV)
53 XEBSN40P10000 AB J Screw, x9 (LCD/CAB-A FIX)
54 XJPS730P06WS0 AB J Screw, x25 (SHIELD FIX_8/OTHER_1/OBON PWB FIX_16)
55
LX-BZA204WJF7 P Screw, x4 (CAB-A/B FIX)
56 LANGKB174WJSA N R CI Angle
57 LCHSMA387WJFW N R Chassis Tray
58 LHLDWA048WJKZ AB J Wire Holder, x4
59 LHLDWA143WJKZ AC J Wire Holder, x6
60 PRDARA491WJFW N R Main Radiator
61 PSHEPA544WJZZ N R Terminal Sheet
62 PSPAZB312WJKZ AD N J Spacer (COOL_25*25_T2.0)
63 PSPAZB313WJKZ AC J Spacer (COOL_20*20_T2.0)
64 PSPAZB658WJKZ N R Spacer (COOL_12*40_T3.0)
65 PZETKA245WJKZ N P Insulator
67 QCNW-G189WJQZ N P Connecting Cord1 (PD:MAIN-POWER)
68 QCNW-G190WJQZ N P Connecting Cord1 (PE:TERMINAL-POWER)
69 XEBS930P10000 AA J Screw, x3 (RADIATOR FIX)
70 TLABNC117WJZZ P Model Label
