LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 14
6. Remove the 9 lock screws , 2 lock screws and the 6 lock hooks . Detach the LCD Panel Module.
7 8
9
8
7
FRONT CABINET
9
