LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 21
13.Remove all the connectors from PWBs.
14.Remove the 4 lock screws , 8 lock screws and the 1 lock screw . Detach the Main Shield.
Wire "US" to WH
Wire "RA" to WH
Wire "US"
Wire "RA"
Wire
Wire "PD"
Wire "PE"
16
17
18
MAIN SHIELD
17
16
17
18
