Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
134
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LISTE DES PIECES
(TU-GD10U-T, TU-45GAD/T)
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque
ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle
que la pi`ece recommand élee parl'usine et dans ce manuel de serv-
ice, peut provoquer une éLelectrocution, un incendie ou toutautre
sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
PARTS LIST
(TU-GD10U-T, TU-45GAD/T)
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which dose no have the same safety characteristic as the fac-
tory recommended replacement parts shown in this service manual
may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
★ MARQUE : SECTION LIVRAISON DES PIECES DE RECHANGE
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
INTEGRATED CIRCUITS
IC2501 RH-iX3370CEN1Q J MSP3440G-QA-B8 AY
IC2502 VHiBH3544F+-1Y J BH3544F-E2 AE
IC2503 VHiBD4742G+-1Y J BD4742G-TR AD
IC2504 VHiBA4560F+-1Y J BA4560F-E2 AD
IC2507 VHiBA4560F+-1Y J BA4560F-E2 AD
IC2508 VHiT7SET08U-1Y J TC7SET08FU AD
IC2509 VHiLVX125FT-1Y J TC74LVX125FT AG
IC2700 VHiNJU26150-1Q J NJU26150FR1 AV
IC2701 VHiNJU26106-1Q J NJU26106FR1 AT
IC2702 VHiAK4586VQ-1Q J AK4586VQ AY
IC2703 RH-iXA167WJZZY J PQ025EZ01ZZ AL
IC2704 VHiN2885D03-1Y J NJM2885DL103TE AE
IC2706 RH-iXA899WJN1Y J AT24C64AN-10SI AL
IC2707 VHiLVX125FT-1Y J TC74LVX125FT AG
IC2708 VHiM62320FP-1Y J M62320FP AH
IC2709 VHiAK4353++-1Y J AK4353VF AR
IC2710 VHiAK5381VT-1Y J AK5381VT AR
TRANSISTORS
Q2501 VSDTC114EE/-1Y J DTC114EE AB
Q2506 VS2SA1530AR-1Y J 2SA1530AR AB
Q2509 VSDTA144EE/-1Y J DTA144EE AA
Q2510 VSDTC144EE/-1Y J DTC144EE AA
Q2513 VSDTA144EE/-1Y J DTA144EE AA
Q2702 VS2SC3928AR-1Y J 2SC3928AR AB
Q2703 VS2SC3928AR-1Y J 2SC3928AR AB
Q2704 VSDTC144EE/-1Y J DTC144EE AA
Q2705 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D2501 VHDDAN222//-1Y J DAN222 AA
D2502 VHDDAN222//-1Y J DAN222 AA
D2503 VHD1SS355//-1Y J 1SS355 AB
D2504 VHD1SS355//-1Y J 1SS355 AB
D2505 VHD1SS355//-1Y J 1SS355 AB
D2506 VHD1SS355//-1Y J 1SS355 AB
D2507 VHD1SS355//-1Y J 1SS355 AB
D2508 VHD1SS355//-1Y J 1SS355 AB
DUNTKC259FE03/FE11/FE12
AV SUB UNIT
(TU-GD10U-T)
DUNTKC259FE03 – AV SUB Unit —
DUNTKC267FE40 –
DVI/HDMI Unit
—
DKEYDC307FE19 J
DIGITAL Unit
CY
DUNTKC505FE01 – TMDS TX Unit —
DUNTKC544FE01 J PC CARD Unit BY
DUNTKC602DE01 –
FORONT Unit
—
DUNTKC603DE01 – AUDIO INTERFACE Unit —
DUNTKC691FE01 J MAIN Unit DM
DUNTKC736FE01 – AV Unit —
RDENCA064WJZZ – POWER SUPPLY Unit —
RDENCA089WJZZ – DC/DC CONVERTER Unit —
B2SX4102BT J 1BIT AMP Unit BL
(TU-45GAD)
DUNTKC259FE11 – AV SUB Unit —
DUNTKC267FE61 – DVI/HDMI Unit —
DUNTKC307FE35 J DIGITAL Unit
DUNTKD051FE08 – TMDS TX Unit —
DUNTKC544FE01 J PC CARD Unit BY
DUNTKC602DE04 – FORONT Unit —
DUNTKC603DE04 – AUDIO INTERFACE Unit —
DUNTKC691FE08 J MAIN Unit
DUNTKC736FE02 – AV Unit —
RDENCA110WJZZ – POWER SUPPLY Unit —
RDENCA089WJZZ – DC/DC CONVERTER Unit —
B2SX4102BT J 1BIT AMP Unit BL
(TU-45GAT)
DUNTKC259FE12 – AV SUB Unit —
DUNTKC267FE62 – DVI/HDMI Unit —
DUNTKC307FE39 J DIGITAL Unit
DUNTKD051FE10 – TMDS TX Unit —
DUNTKC544FE01 J PC CARD Unit BY
DUNTKC602DE05 – FORONT Unit —
DUNTKC603DE05 – AUDIO INTERFACE Unit —
DUNTKC691FE10 J MAIN Unit
DUNTKC736FE03 – AV Unit —
RDENCA064WJZZ – POWER SUPPLY Unit —
RDENCA089WJZZ – DC/DC CONVERTER Unit —
B2SX4102BT J 1BIT AMP Unit BL
To Next Page
