Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
175
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
CABINET AND MECHANICAL PARTS
1 CANGTA143WJ01 J Rear Frame Ass’y AU
(TU-GD10U-T)
1 CANGTA143WJ02 J Rear Frame Ass’y
(LC-45GAD)
1 CANGTA143WJ03 J Rear Frame Ass’y
(LC-45GAT)
1-1
Not Available
– Rear Frame —
1-2 HiNDPB098WJSA J Rear Indicator AN
(TU-GD10U-T)
1-2 HiNDPB254WJSA J Rear Indicator
(LC-45GAD)
1-2 HiNDPB255WJSA J Rear Indicator
(LC-45GAT)
1-3 QEARZA020WJFW J Earth Spring, x2 AC
2 CCABAA469WJ03 J Chassis Frame Ass’y BB
2-1
Not Available
– Chassis Frame —
2-2 LHLDW1121GEZZ J Wire Holder, x2 AB
2-3 LHLDWA023WJKZ J Wire Holder AC
2-4 LHLDWA032WJZZ J Wire Holder AD
2-5 QEARBA010WJFW J Earth Spring AG
2-6 XJPSN30P08XS0 J Screw, x2 AA
2-7 LANGTA106WJFW J Fixing Metal AL
2-8 LANGTA107WJSA J Fixing Metal AM
3 CCABBA334WJ14 J Bottom Cabinet Ass’y AY
(TU-GD10U-T)
3 CCABBA334WJ15 J Bottom Cabinet Ass’y
(LC-45GAD)
3 CCABBA334WJ16 J Bottom Cabinet Ass’y
(LC-45GAT)
3-1
Not Available
– Bottom Cabinet —
3-2 GLEGGA034WJZZ J Rubber Leg, x4 AD
3-3 TLABZA764WJSA J Label AE
4 CCABBA407WJ02 J Top Cabinet Ass’y AY
(TU-GD10U-T)
4 CCABBA407WJ05 J Top Cabinet Ass’y
(LC-45GAD)
4 CCABBA407WJ06 J Top Cabinet Ass’y
(LC-45GAT)
4-1
Not Available
–Top Cabinet —
4-2 TCAUHA050WJSB J Caution Label
(TU-GD10U-T)
4-2 TCAUHA086WJSB J Caution Label
(LC-45GAD)
4-2 TCAUHA071WJSB J Caution Label AE
(LC-45GAT)
4-3 PSLDMA571WJZZ J Gasket AQ
5 CHLDZA240WJ01 J Fan Holder Ass’y AH
5-1
Not Available
– Fan Holder —
5-2 PSPAGA133WJZZ J Spacer, x4 AB
6 CHLDZA306WJ01 J Fan Holder Ass’y AH
6-1
Not Available
– Fan Holder —
6-2 PSPAGA133WJZZ J Spacer, x4 AB
7 CPNLCA122WJ04 J Front Panel Ass’y BG
(TU-GD10U-T)
7 CPNLCA122WJ05 J Front Panel Ass’y BD
(LC-45GAD/DAT)
7-1
Not Available
–Front Panel —
7-2 GCOVAA638WJSA J B-CAS Card Cover AK
7-3 GDORFA111WJSA J Door AY
(TU-GD10U-T)
7-3 GDORFA091WJSB J Door AW
(LC-45GAD/DAT)
7-4 HDECQA333WJSA J LED Decoration Cover AF
7-5 HiNDPA758WJSA J PC CARD Indication Label AE
7-6 HiNDPA832WJSB J Terminal Indication Label AF
7-7 JBTN-A252WJKA J Power Button AH
7-8 LANGTA121WJFW J Hinge Angle, x2 AC
7-9 LHLDZ3057GEZZ J Magnet Catch, x2 AE
7-10 LHLDZA323WJSA J Hinge Fixed Holder, x3 AL
7-11 MHNG-1072CEZZ J Hinge, x3 AH
7-12 PSPAGA191WJZZ J Spacer, x2 AB
7-13 PSPAZ0457CESA J Spacer AA
7-15 XEBSN30P08000 J Screw, x6 AA
8 CSLDMA450WJ01 J Digital Shield Ass’y AU
8-1
Not Available
– Shield —
8-2 PRDARA104WJFW J Heat Sink AF
8-3 XJPSN30P08XS0 J Screw, x2 AA
9 CANGTA118WJ01 J Tuner Earth Angle Ass’y AQ
9-1
Not Available
–Tuner Earth Angle —
9-2 PSPAHA328WJZZ J Spacer AC
9-3 QEARZA058WJZZ J Gasket, x2 AH
10 GCOVAA624WJKA J Side Shield(L) AN
11 GCOVAA625WJKA J Side Shield(R) AN
12 GCOVAA678WJKA J SD Cover AE
14 PMLT-A159WJZZ J Gasket AE
15 PRDARA135WJFW J Heat Sink AN
16 LBSHZA003WJZZ J Fan Bush, x8 AD
17 LHLDW1009CEZZ J Wire Holder AA
18 LHLDW1046CEZZ J Wire Holder AA
19 LHLDW1060CEZZ J Wire Holder AB
20 LHLDW1081GEZZ J Wire Holder AB
21 LHLDW1090GEZZ J Wire Holder AB
22 LHLDWA038WJZZ J Wire Holder AC
23 LX-BZ3434CEFN J System Cable, x2 AB
24 LX-NZ3047GEZZ J Nut AA
25 NFANR0120CEZZ J FAN AU
26 NFANR0126CEZZ J FAN AT
27 NSFTZ0134CEFW J Shaft, x6 AD
28 PSLDMA303WJFW J Front Shield AL
29 PSLDMA451WJFW J TMDS Shield AH
30 PSLDMA342WJFW J PC Card Shield AF
31 PSLDMA425WJFW J RCA Shield AD
33 DUNTKC259FE03 – AV SUB Unit (TU-GD10U-T) —
33 DUNTKC259FE11 – AV SUB Unit (TU-45GAD) —
33 DUNTKC259FE12 – AV SUB Unit (TU-45GAT) —
34 DUNTKC505FE01 – TMDS TX Unit —
(TU-GD10U-T)
34 DUNTKD051FE08 – TMDS TX Unit (TU-45GAD) —
34 DUNTKD051FE10 – TMDS TX Unit (TU-45GAT) —
35 DUNTKC544FE01 J PC CARD Unit BY
36 DUNTKC267FE40 –
DVI/HDMI Unit (TU-GD10U-T)
—
36 DUNTKC267FE57 – DVI/HDMI Unit (TU-45GAD) —
36 DUNTKC267FE58 – DVI/HDMI Unit (TU-45GAT) —
37 DKEYDC307FE19 J
DIGITAL Unit (TU-GD10U-T)
CY
37 DUNTKC307FE35 J DIGITAL Unit (TU-45GAD)
37 DUNTKC307FE39 J DIGITAL Unit (TU-45GAT)
38 DUNTKC602DE01 –
FORONT Unit (TU-GD10U-T)
—
38 DUNTKC602DE04 – FORONT Unit (TU-45GAD) —
38 DUNTKC602DE05 – FORONT Unit (TU-45GAT) —
39 DUNTKC603DE01 – AUDIO INTERFACE Unit —
(TU-GD10U-T)
39 DUNTKC603DE04 – AUDIO INTERFACE Unit —
(TU-45GAD)
39 DUNTKC603DE05 – AUDIO INTERFACE Unit —
(TU-45GAT)
40 DUNTKC691FE01 J MAIN Unit (TU-GD10U-T) DM
40 DUNTKC691FE08 J MAIN Unit (TU-45GAD)
40 DUNTKC691FE10 J MAIN Unit (TU-45GAT)
41 DUNTKC736FE01 – AV Unit (TU-GD10U-T) —
41 DUNTKC736FE02 – AV Unit (TU-45GAD) —
41 DUNTKC736FE03 – AV Unit (TU-45GAT) —
42 RDENCA064WJZZ – POWER SUPPLY Unit —
(TU-GD10U-T/LC-45GAT)
42 RDENCA110WJZZ – POWER SUPPLY Unit —
(LC-45GAD)
43 RDENCA089WJZZ – DC/DC CONVERTER Unit —
44 B2SX4102BT J 1BIT AMP Unit BL
45 PSLDMA404WJFW J DVI Shield AF
46 LANGTA154WJN1 J AV Mount Angle AQ
