Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
176
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
CABINET AND MECHANICAL PARTS
(Continued)
47 QCNW-C030WJPZ J Connecting Cord, AV-DVI AF
48 QCNW-C026WJQZ J Connecting Cord AH
49 QCNW-C028WJPZ J Connecting Cord, AV-FRONT AR
50 QCNW-C033WJQZ J Connecting Cord, AV-AUDIO IF AF
51 QCNW-C903WJQZ J Connecting Cord AQ
52 QCNW-C014WJQZ J Connecting Cord AG
53 QCNW-C034WJQZ J Connecting Cord AG
54 QCNW-C035WJQZ J Connecting Cord AE
55 QCNW-C730WJQZ J Connecting Cord AX
56 QCNW-C806WJQZ J Connecting Cord AN
57 QCNW-C807WJPZ J Connecting Cord AX
58 QCNW-C808WJPZ J Connecting Cord AY
59 QCNW-C810WJPZ J Connecting Cord AW
(TU-GD10U-T)
59 QCNW-D420WJQZ J Connecting Cord AK
(LC-45GAD/DAT)
60 QPWBHC571WJQZ J Printed Wiring Board AX
61 QPWBHC572WJQZ J Printed Wiring Board AN
62 QEARBA009WJFW J Ground-Part AG
64 LANGTA168WJFW J TMDS PWB Angle AP
65 LHLDWA023WJKZ J Wire Holder AC
66 LHLDW1121GEZZ J Wire Holder AB
67 LANGTA116WJN1 J DVI Angle AN
68 LHLDWA035WJZZ J Wire Holder AC
69 LHLDFA021WJZZ J Wire Holder AC
70 LHLDW1090GEZZ J Wire Holder, x2 AB
71 PSPAZA398WJKA J Spacer, x2 AK
72 LANGFA086WJFW J MAIN PWB Angle AH
73 LANGTA111WJN1 J Card PWB Angle AQ
74 TLABK0023TAZZ J Label AA
75 TLABMB113WJSB J Model Label AD
(TU-GD10U-T)
75 TLABMB416WJZZ J Model Label
(TU-45GAD)
75 TLABMB417WJZZ J Model Label
(TU-45GAT)
76 GCOVHA042WJKA J PC Card Cover AE
(TU-GD10U-T)
77 PMLT-A170WJZZ J Absorber (TU-GD10U-T) AD
78 PMLT-A171WJZZ J Absorber (TU-GD10U-T) AE
79 PSPAZA565WJKZ J Spacer AF
80 XBPSN30P06000 J Screw, x6 AA
81 XEBSN26P06000 J Screw, x1 AA
82 XEBSN30P08000 J Screw, x4 AA
83 XJPS930P08XS0 J Screw, x16 AA
84 XJPSN30P08XS0 J Screw, x71 AA
85 XBPSN20P12JS0 J Screw, x6 AB
86 95KECB8161ZZ J Connecting Cord AL
87 95KECB8162ZZ J Connecting Cord AL
88 95KECB8163ZZ J Connecting Cord AL
89 PMLT-A118WJZZ J Absorber AD
