Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
180
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
(LC-45GX6U)
DUNTKC470VJ01 J TMDS RX Unit BZ
DUNTKC471UJ01 – INVERTER 1 Unit —
DUNTKC472UJ01 – INVERTER 2 Unit —
DUNTKC473UJ01 – INVERTER 3 Unit —
DUNTKC474UJ01 – INVERTER 4 Unit —
DUNTKC475UJ01 – MOTOR CONTROL Unit —
DUNTKC476UJ01 – R/C LED Unit —
DUNTKC478UJ01 J TOP LCD CONTROLLER Unit CM
DUNTKC479UJ01 J BOTTOM LCD CONTROLLER Unit BU
DUNTKC504VJ01 – LINE FILTER Unit —
DUNTKC506UJ01 – DC/DC Unit —
DUNTKC507UJ01 – CS CONTROL Unit —
DUNTKC508UJ01 – KEY Unit —
RDENCA083WJZZ – POWER SUPPLY Unit —
(LC-45GX6D)
DUNTKC470VJ08 J TMDS RX Unit
DUNTKC471UJ08 – INVERTER 1 Unit —
DUNTKC472UJ08 – INVERTER 2 Unit —
DUNTKC473UJ08 – INVERTER 3 Unit —
DUNTKC474UJ08 – INVERTER 4 Unit —
DUNTKC475UJ08 – MOTOR CONTROL Unit —
DUNTKC476UJ08 – R/C LED Unit —
DUNTKC478UJ11 J TOP LCD CONTROLLER Unit
DUNTKC479UJ11 J BOTTOM LCD CONTROLLER Unit
DUNTKC504VJ08 – LINE FILTER Unit —
DUNTKC506UJ08 – DC/DC Unit —
DUNTKC507UJ08 – CS CONTROL Unit —
DUNTKC508UJ08 – KEY Unit —
RDENCA086WJZZ – POWER SUPPLY Unit —
(LC-45GX6T)
DUNTKC470VJ10 J TMDS RX Unit
DUNTKC471UJ10 – INVERTER 1 Unit —
DUNTKC472UJ10 – INVERTER 2 Unit —
DUNTKC473UJ10 – INVERTER 3 Unit —
LISTE DES PIECES
(LC-45GX6U/D/T)
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle
que la pi`ece recommand élee parl'usine et dans ce manuel de serv-
ice, peut provoquer une éLelectrocution, un incendie ou toutautre
sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
PARTS LIST
(LC-45GX6U/D/T)
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which dose no have the same safety characteristic as the fac-
tory recommended replacement parts shown in this service manual
may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
★ MARQUE : SECTION LIVRAISON DES PIECES DE RECHANGE
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA030WJZZ J 45” Wide LCD Panel Unit HE
(LK445D3FZA0)
DUNTKC474UJ10 – INVERTER 4 Unit —
DUNTKC475UJ10 – MOTOR CONTROL Unit —
DUNTKC476UJ10 – R/C LED Unit —
DUNTKC478UJ12 J TOP LCD CONTROLLER Unit
DUNTKC479UJ12 J BOTTOM LCD CONTROLLER Unit
DUNTKC504VJ10 – LINE FILTER Unit —
DUNTKC506UJ10 – DC/DC Unit —
DUNTKC507UJ10 – CS CONTROL Unit —
DUNTKC508UJ10 – KEY Unit —
RDENCA083WJZZ – POWER SUPPLY Unit —
