Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
184
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
INTEGRATED CIRCUITS
IC7301 VHiBD9884FV-1Y J BD9884FV-E2 AM
IC7302 VHiBA00ASFP-1Y J BA00ASFP-E2 AG
IC7303 VHiBA10393F2EY J BA10393F-E2 AD
TRANSISTORS
Q7303 VSRSS075P03-1Y J RSS075P03 AF
Q7304 VSRSS090N03-1Y J RSS090N03 AE
Q7309 VSRSS075P03-1Y J RSS075P03 AF
Q7310 VSRSS090N03-1Y J RSS090N03 AE
Q7313 VSRSS075P03-1Y J RSS075P03 AF
Q7314 VSRSS090N03-1Y J RSS090N03 AE
Q7317 VSRSS075P03-1Y J RSS075P03 AF
Q7318 VSRSS090N03-1Y J RSS090N03 AE
Q7323 VSRSS075P03-1Y J RSS075P03 AF
Q7324 VSRSS090N03-1Y J RSS090N03 AE
Q7327 VSRSS075P03-1Y J RSS075P03 AF
Q7328 VSRSS090N03-1Y J RSS090N03 AE
Q7329 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7330 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7335 VSUM6K1NTN+-1Y J UM6K1NTN AC
DIODES
D7301 VHDDAN217U+-1Y J DAN217U AB
D7302 VHDDAN217U+-1Y J DAN217U AB
D7303 VHDDAN217U+-1Y J DAN217U AB
D7304 VHDDAN217U+-1Y J DAN217U AB
D7305 VHDRB160M30-1Y J RB160M30 AC
D7306 VHDRB160M30-1Y J RB160M30 AC
D7307 VHDDAN217U+-1Y J DAN217U AB
D7308 VHDDAN217U+-1Y J DAN217U AB
D7309 VHDDAN217U+-1Y J DAN217U AB
D7310 VHDDAN217U+-1Y J DAN217U AB
D7311 VHDRB160M30-1Y J RB160M30 AC
D7312 VHDRB160M30-1Y J RB160M30 AC
D7313 VHDDAN217U+-1Y J DAN217U AB
D7314 VHDDAN217U+-1Y J DAN217U AB
D7315 VHDDAN217U+-1Y J DAN217U AB
D7316 VHDDAN217U+-1Y J DAN217U AB
D7317 VHDRB160M30-1Y J RB160M30 AC
D7318 VHDRB160M30-1Y J RB160M30 AC
D7320 VHDDAN217U+-1Y J DAN217U AB
D7321 VHDDAN217U+-1Y J DAN217U AB
D7322 VHDDAN217U+-1Y J DAN217U AB
D7323 VHDDAN217U+-1Y J DAN217U AB
D7324 VHDRB160M30-1Y J RB160M30 AC
D7325 VHDRB160M30-1Y J RB160M30 AC
D7326 VHDDAN217U+-1Y J DAN217U AB
D7327 VHDDAN217U+-1Y J DAN217U AB
D7328 VHDDAN217U+-1Y J DAN217U AB
D7329 VHDDAN217U+-1Y J DAN217U AB
D7330 VHDRB160M30-1Y J RB160M30 AC
D7331 VHDRB160M30-1Y J RB160M30 AC
D7332 VHDDAN217U+-1Y J DAN217U AB
D7333 VHDDAN217U+-1Y J DAN217U AB
D7334 VHDDAN217U+-1Y J DAN217U AB
D7335 VHDDAN217U+-1Y J DAN217U AB
D7336 VHDRB160M30-1Y J RB160M30 AC
D7337 VHDRB160M30-1Y J RB160M30 AC
D7339 VHD1SS355//-1Y J 1SS355 AB
D7340 RH-EX1394CEZZY J Zener Diode AB
D7341 RH-EX1394CEZZY J Zener Diode AB
TRANSFORMERS
å T7301 RTRNZA056WJZZ J RNZA056WJ AN
å T7302 RTRNZA056WJZZ J RNZA056WJ AN
å T7303 RTRNZA056WJZZ J RNZA056WJ AN
å T7304 RTRNZA056WJZZ J RNZA056WJ AN
å T7305 RTRNZA056WJZZ J RNZA056WJ AN
å T7306 RTRNZA056WJZZ J RNZA056WJ AN
DUNTKC471UJ01/08/10
INVERTER 1 UNIT
CAPACITORS
C5901 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5902 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5903 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5904 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5905 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5906 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5907 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5908 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5909 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5910 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5911 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5912 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7301 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7302 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7303 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7304 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7306 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7307 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7308 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7309 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7310 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7311 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7312 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7313 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7314 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7317 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7318 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7319 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7320 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7321 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7322 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7323 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7324 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7325 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7327 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7328 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7330 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7331 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7332 RC-EZA480WJZZY J 680 25V Electrolytic AD
C7333 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7334 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7335 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7336 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7338 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7339 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7340 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7341 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7342 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7343 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7344 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7345 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7346 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7349 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7350 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7351 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7352 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7353 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7354 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7355 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7356 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7357 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7359 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7360 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7362 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7363 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7364 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7366 VCCCCY1HH391JY J 390p 50V Ceramic AB
C7367 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7368 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7369 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7370 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7371 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7373 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C7374 VCKYCY1CB224KY J 0.22 16V Ceramic AB
C7375 VCKYCY1CB224KY J 0.22 16V Ceramic AB
