Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
186
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
DUNTKC472UJ01/08/10
INVERTER 2 UNIT
INTEGRATED CIRCUITS
IC7401 VHiBD9884FV-1Y J BD9884FV-E2 AM
IC7402 VHiBA00ASFP-1Y J BA00ASFP-E2 AG
IC7403 VHiBA10393F2EY J BA10393F-E2 AD
TRANSISTORS
Q7403 VSRSS075P03-1Y J RSS075P03 AF
Q7404 VSRSS090N03-1Y J RSS090N03 AE
Q7409 VSRSS075P03-1Y J RSS075P03 AF
Q7410 VSRSS090N03-1Y J RSS090N03 AE
Q7413 VSRSS075P03-1Y J RSS075P03 AF
Q7414 VSRSS090N03-1Y J RSS090N03 AE
Q7417 VSRSS075P03-1Y J RSS075P03 AF
Q7418 VSRSS090N03-1Y J RSS090N03 AE
Q7423 VSRSS075P03-1Y J RSS075P03 AF
Q7424 VSRSS090N03-1Y J RSS090N03 AE
Q7427 VSRSS075P03-1Y J RSS075P03 AF
Q7428 VSRSS090N03-1Y J RSS090N03 AE
Q7429 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7430 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7435 VSUM6K1NTN+-1Y J UM6K1NTN AC
DIODES
D7401 VHDDAN217U+-1Y J DAN217U AB
D7402 VHDDAN217U+-1Y J DAN217U AB
D7403 VHDDAN217U+-1Y J DAN217U AB
D7404 VHDDAN217U+-1Y J DAN217U AB
D7405 VHDRB160M30-1Y J RB160M30 AC
D7406 VHDRB160M30-1Y J RB160M30 AC
D7407 VHDDAN217U+-1Y J DAN217U AB
D7408 VHDDAN217U+-1Y J DAN217U AB
D7409 VHDDAN217U+-1Y J DAN217U AB
D7410 VHDDAN217U+-1Y J DAN217U AB
D7411 VHDRB160M30-1Y J RB160M30 AC
D7412 VHDRB160M30-1Y J RB160M30 AC
D7413 VHDDAN217U+-1Y J DAN217U AB
D7414 VHDDAN217U+-1Y J DAN217U AB
D7415 VHDDAN217U+-1Y J DAN217U AB
D7416 VHDDAN217U+-1Y J DAN217U AB
D7417 VHDRB160M30-1Y J RB160M30 AC
D7418 VHDRB160M30-1Y J RB160M30 AC
D7420 VHDDAN217U+-1Y J DAN217U AB
D7421 VHDDAN217U+-1Y J DAN217U AB
D7422 VHDDAN217U+-1Y J DAN217U AB
D7423 VHDDAN217U+-1Y J DAN217U AB
D7424 VHDRB160M30-1Y J RB160M30 AC
D7425 VHDRB160M30-1Y J RB160M30 AC
D7426 VHDDAN217U+-1Y J DAN217U AB
D7427 VHDDAN217U+-1Y J DAN217U AB
D7428 VHDDAN217U+-1Y J DAN217U AB
D7429 VHDDAN217U+-1Y J DAN217U AB
D7430 VHDRB160M30-1Y J RB160M30 AC
D7431 VHDRB160M30-1Y J RB160M30 AC
D7432 VHDDAN217U+-1Y J DAN217U AB
D7433 VHDDAN217U+-1Y J DAN217U AB
D7434 VHDDAN217U+-1Y J DAN217U AB
D7435 VHDDAN217U+-1Y J DAN217U AB
D7436 VHDRB160M30-1Y J RB160M30 AC
D7437 VHDRB160M30-1Y J RB160M30 AC
D7439 VHD1SS355//-1Y J 1SS355 AB
D7440 RH-EX1394CEZZY J Zener Diode AB
D7441 RH-EX1394CEZZY J Zener Diode AB
TRANSFORMERS
å T7401 RTRNZA056WJZZ J RNZA056WJ AN
å T7402 RTRNZA056WJZZ J RNZA056WJ AN
å T7403 RTRNZA056WJZZ J RNZA056WJ AN
å T7404 RTRNZA056WJZZ J RNZA056WJ AN
å T7405 RTRNZA056WJZZ J RNZA056WJ AN
å T7406 RTRNZA056WJZZ J RNZA056WJ AN
CAPACITORS
C5915 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5916 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5917 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5918 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5919 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5920 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5921 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5922 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5923 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5924 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5925 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5926 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7401 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7402 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7403 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7404 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7406 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7407 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7408 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7409 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7410 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7411 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7412 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7413 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7414 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7417 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7418 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7419 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7420 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7421 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7422 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7423 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7424 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7425 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7427 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7428 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7430 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7431 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7432 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7433 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7434 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7435 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7436 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7438 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7439 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7440 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7441 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7442 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7443 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7444 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7445 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7446 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7449 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7450 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7451 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7452 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7453 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7454 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7455 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7456 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7457 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7459 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7460 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7462 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7463 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7464 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7466 VCCCCY1HH391JY J 390p 50V Ceramic AB
C7467 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7468 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7469 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7470 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7471 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7473 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C7474 VCKYCY1CB224KY J 0.22 16V Ceramic AB
C7475 VCKYCY1CB224KY J 0.22 16V Ceramic AB
