Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
188
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
DUNTKC473UJ01/08/10
INVERTER 3 UNIT
INTEGRATED CIRCUITS
IC7501 VHiBD9884FV-1Y J BD9884FV-E2 AM
IC7502 VHiBA00ASFP-1Y J BA00ASFP-E2 AG
IC7503 VHiBA10393F2EY J BA10393F-E2 AD
TRANSISTORS
Q7503 VSRSS075P03-1Y J RSS075P03 AF
Q7504 VSRSS090N03-1Y J RSS090N03 AE
Q7509 VSRSS075P03-1Y J RSS075P03 AF
Q7510 VSRSS090N03-1Y J RSS090N03 AE
Q7513 VSRSS075P03-1Y J RSS075P03 AF
Q7514 VSRSS090N03-1Y J RSS090N03 AE
Q7517 VSRSS075P03-1Y J RSS075P03 AF
Q7518 VSRSS090N03-1Y J RSS090N03 AE
Q7523 VSRSS075P03-1Y J RSS075P03 AF
Q7524 VSRSS090N03-1Y J RSS090N03 AE
Q7527 VSRSS075P03-1Y J RSS075P03 AF
Q7528 VSRSS090N03-1Y J RSS090N03 AE
Q7529 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7530 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7535 VSUM6K1NTN+-1Y J UM6K1NTN AC
DIODES
D7501 VHDDAN217U+-1Y J DAN217U AB
D7502 VHDDAN217U+-1Y J DAN217U AB
D7503 VHDDAN217U+-1Y J DAN217U AB
D7504 VHDDAN217U+-1Y J DAN217U AB
D7505 VHDRB160M30-1Y J RB160M30 AC
D7506 VHDRB160M30-1Y J RB160M30 AC
D7507 VHDDAN217U+-1Y J DAN217U AB
D7508 VHDDAN217U+-1Y J DAN217U AB
D7509 VHDDAN217U+-1Y J DAN217U AB
D7510 VHDDAN217U+-1Y J DAN217U AB
D7511 VHDRB160M30-1Y J RB160M30 AC
D7512 VHDRB160M30-1Y J RB160M30 AC
D7513 VHDDAN217U+-1Y J DAN217U AB
D7514 VHDDAN217U+-1Y J DAN217U AB
D7515 VHDDAN217U+-1Y J DAN217U AB
D7516 VHDDAN217U+-1Y J DAN217U AB
D7517 VHDRB160M30-1Y J RB160M30 AC
D7518 VHDRB160M30-1Y J RB160M30 AC
D7520 VHDDAN217U+-1Y J DAN217U AB
D7521 VHDDAN217U+-1Y J DAN217U AB
D7522 VHDDAN217U+-1Y J DAN217U AB
D7523 VHDDAN217U+-1Y J DAN217U AB
D7524 VHDRB160M30-1Y J RB160M30 AC
D7525 VHDRB160M30-1Y J RB160M30 AC
D7526 VHDDAN217U+-1Y J DAN217U AB
D7527 VHDDAN217U+-1Y J DAN217U AB
D7528 VHDDAN217U+-1Y J DAN217U AB
D7529 VHDDAN217U+-1Y J DAN217U AB
D7530 VHDRB160M30-1Y J RB160M30 AC
D7531 VHDRB160M30-1Y J RB160M30 AC
D7532 VHDDAN217U+-1Y J DAN217U AB
D7533 VHDDAN217U+-1Y J DAN217U AB
D7534 VHDDAN217U+-1Y J DAN217U AB
D7535 VHDDAN217U+-1Y J DAN217U AB
D7536 VHDRB160M30-1Y J RB160M30 AC
D7537 VHDRB160M30-1Y J RB160M30 AC
D7539 VHD1SS355//-1Y J 1SS355 AB
D7540 RH-EX1394CEZZY J Zener Diode AB
D7541 RH-EX1394CEZZY J Zener Diode AB
TRANSFORMERS
å T7501 RTRNZA057WJZZ J RNZA057WJ AN
å T7502 RTRNZA057WJZZ J RNZA057WJ AN
å T7503 RTRNZA057WJZZ J RNZA057WJ AN
å T7504 RTRNZA057WJZZ J RNZA057WJ AN
å T7505 RTRNZA057WJZZ J RNZA057WJ AN
å T7506 RTRNZA057WJZZ J RNZA057WJ AN
CAPACITORS
C5931 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5932 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5933 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5934 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5935 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5936 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5937 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5938 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5939 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5940 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5941 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5942 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7501 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7502 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7503 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7504 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7506 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7507 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7508 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7509 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7510 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7511 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7512 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7513 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7514 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7517 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7518 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7519 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7520 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7521 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7522 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7523 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7524 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7525 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7527 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7528 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7530 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7531 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7532 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7533 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7534 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7535 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7536 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7538 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7539 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7540 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7541 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7542 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7543 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7544 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7545 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7546 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7549 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7550 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7551 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7552 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7553 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7554 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7555 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7556 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7557 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7559 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7560 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7562 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7563 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7564 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7566 VCCCCY1HH391JY J 390p 50V Ceramic AB
C7567 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7568 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7569 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7570 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7571 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7573 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C7574 VCKYCY1CB224KY J 0.22 16V Ceramic AB
C7575 VCKYCY1CB224KY J 0.22 16V Ceramic AB
