Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
190
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
INTEGRATED CIRCUITS
IC7601 VHiBD9884FV-1Y J BD9884FV-E2 AM
IC7602 VHiBA00ASFP-1Y J BA00ASFP-E2 AG
IC7603 VHiBA10393F2EY J BA10393F-E2 AD
TRANSISTORS
Q7603 VSRSS075P03-1Y J RSS075P03 AF
Q7604 VSRSS090N03-1Y J RSS090N03 AE
Q7609 VSRSS075P03-1Y J RSS075P03 AF
Q7610 VSRSS090N03-1Y J RSS090N03 AE
Q7613 VSRSS075P03-1Y J RSS075P03 AF
Q7614 VSRSS090N03-1Y J RSS090N03 AE
Q7617 VSRSS075P03-1Y J RSS075P03 AF
Q7618 VSRSS090N03-1Y J RSS090N03 AE
Q7623 VSRSS075P03-1Y J RSS075P03 AF
Q7624 VSRSS090N03-1Y J RSS090N03 AE
Q7627 VSRSS075P03-1Y J RSS075P03 AF
Q7628 VSRSS090N03-1Y J RSS090N03 AE
Q7629 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7630 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q7635 VSUM6K1NTN+-1Y J UM6K1NTN AC
DIODES
D7601 VHDDAN217U+-1Y J DAN217U AB
D7602 VHDDAN217U+-1Y J DAN217U AB
D7603 VHDDAN217U+-1Y J DAN217U AB
D7604 VHDDAN217U+-1Y J DAN217U AB
D7605 VHDRB160M30-1Y J RB160M30 AC
D7606 VHDRB160M30-1Y J RB160M30 AC
D7607 VHDDAN217U+-1Y J DAN217U AB
D7608 VHDDAN217U+-1Y J DAN217U AB
D7609 VHDDAN217U+-1Y J DAN217U AB
D7610 VHDDAN217U+-1Y J DAN217U AB
D7611 VHDRB160M30-1Y J RB160M30 AC
D7612 VHDRB160M30-1Y J RB160M30 AC
D7613 VHDDAN217U+-1Y J DAN217U AB
D7614 VHDDAN217U+-1Y J DAN217U AB
D7615 VHDDAN217U+-1Y J DAN217U AB
D7616 VHDDAN217U+-1Y J DAN217U AB
D7617 VHDRB160M30-1Y J RB160M30 AC
D7618 VHDRB160M30-1Y J RB160M30 AC
D7620 VHDDAN217U+-1Y J DAN217U AB
D7621 VHDDAN217U+-1Y J DAN217U AB
D7622 VHDDAN217U+-1Y J DAN217U AB
D7623 VHDDAN217U+-1Y J DAN217U AB
D7624 VHDRB160M30-1Y J RB160M30 AC
D7625 VHDRB160M30-1Y J RB160M30 AC
D7626 VHDDAN217U+-1Y J DAN217U AB
D7627 VHDDAN217U+-1Y J DAN217U AB
D7628 VHDDAN217U+-1Y J DAN217U AB
D7629 VHDDAN217U+-1Y J DAN217U AB
D7630 VHDRB160M30-1Y J RB160M30 AC
D7631 VHDRB160M30-1Y J RB160M30 AC
D7632 VHDDAN217U+-1Y J DAN217U AB
D7633 VHDDAN217U+-1Y J DAN217U AB
D7634 VHDDAN217U+-1Y J DAN217U AB
D7635 VHDDAN217U+-1Y J DAN217U AB
D7636 VHDRB160M30-1Y J RB160M30 AC
D7637 VHDRB160M30-1Y J RB160M30 AC
D7639 VHD1SS355//-1Y J 1SS355 AB
D7640 RH-EX1394CEZZY J Zener Diode AB
D7641 RH-EX1394CEZZY J Zener Diode AB
TRANSFORMERS
å T7601 RTRNZA057WJZZ J RNZA057WJ AN
å T7602 RTRNZA057WJZZ J RNZA057WJ AN
å T7603 RTRNZA057WJZZ J RNZA057WJ AN
å T7604 RTRNZA057WJZZ J RNZA057WJ AN
å T7605 RTRNZA057WJZZ J RNZA057WJ AN
å T7606 RTRNZA057WJZZ J RNZA057WJ AN
CAPACITORS
C5945 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5946 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5947 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5948 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5949 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5950 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5951 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5952 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5953 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5954 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5955 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C5956 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7601 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7602 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7603 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7604 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7606 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7607 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7608 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7609 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7610 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7611 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7612 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7613 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7614 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7617 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7618 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7619 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7620 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7621 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7622 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7623 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7624 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7625 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7627 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7628 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7630 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7631 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7632 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7633 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7634 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7635 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7636 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7638 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7639 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7640 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7641 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7642 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7643 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7644 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7645 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7646 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7649 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7650 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7651 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7652 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7653 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7654 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7655 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7656 RC-KZA191WJZZY J 27 4kV Ceramic AD
C7657 VCKYCY1HB182KY J 1800p 50V Ceramic AA
C7659 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7660 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7662 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7663 RC-KZA068WJZZY J 4.7 25V Ceramic AC
C7664 RC-EZA480WJZZ J 680 25V Electrolytic AD
C7666 VCCCCY1HH391JY J 390p 50V Ceramic AB
C7667 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7668 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7669 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C7670 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C7671 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7673 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C7674 VCKYCY1CB224KY J 0.22 16V Ceramic AB
C7675 VCKYCY1CB224KY J 0.22 16V Ceramic AB
DUNTKC474UJ01/08/10
INVERTER 4 UNIT
