Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code
192
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
PACKAGED CIRCUIT
TH601 VHHM1103J03-1Y J Thermistor AC
MISCELLANEOUS PARTS
P601 QPLGNA047WJZZ J Plug, 8Pin(SO) AC
P602 QPLGNA048WJZZ J Plug, 9Pin(MC) AC
P603 QTANAA005WJZZ J Terminal AG
LUG601 QLUGHA002WJZZ J Lug AB
LUG602 QLUGHA002WJZZ J Lug AB
LUG603 QLUGHA002WJZZ J Lug AB
LUG604 QLUGHA002WJZZ J Lug AB
FB604 RBLN-0210TAZZY J Ferrite Bead AB
FB605 RBLN-0210TAZZY J Ferrite Bead AB
FB606 RBLN-0210TAZZY J Ferrite Bead AB
FB607 RBLN-0210TAZZY J Ferrite Bead AB
DUNTKC475UJ01/08/10
MOTOR CONTROL UNIT
INTEGRATED CIRCUIT
IC101 VHiTPS850++-1Y J TPS850 AG
OPT DEVICE
D102 VHPCL221HR+-1Y J PhotoDiode AD
TRANSISTORS
Q101 VS2SC2712Y/-1Y J 2SC2712Y AB
Q102 VS2SC2712Y/-1Y J 2SC2712Y AB
Q103 VS2SC2712Y/-1Y J 2SC2712Y AB
Q104 VS2SC2712Y/-1Y J 2SC2712Y AB
DIODES AND LED’S
D101 RH-PX0445CEZZY J PhotoDiode AM
D103 RH-PX0421CEZZY J PhotoDiode AD
D104 RH-EXA092WJZZY J Zener Diode,12V AB
CAPACITORS
C101 VCEASX1CN106MY J 10 16V Electrolytic AC
C102 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C103 VCEASX1CN107MY J 100 16V Electrolytic AC
C104 RC-KZ0083TAZZY J 2.2 10V Ceramic AC
RESISTORS
R101 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R102 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R103 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R104 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R107 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R108 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R109 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R112 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R116 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P102 QPLGNA330WJZZY J Plug, 10Pin(RM) AC
RMC101 RRMCU0239CEZZ J Remote Receiver AG
SLD101 PSLDM4646CEFW J Shield AD
DUNTKC476UJ01/08/10
R/C LED UNIT
