Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
209
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
C7910 95CC1095EQ103 J 0.01 50V Ceramic AC
C7911 95CC1094EQ101 J 100p 50V Ceramic AC
C7922 95CC1152EC224 J 0.22(B) 50V Ceramic AE
C7923 95CC1094EQ101 J 100p 50V Ceramic AC
C7925 95CC1095EQ104 J 0.1 50V Ceramic AC
C7941 95CC30A0EQ220 J 22(ZL) 50V Electrolytic AE
C7942 95CC1094EQ102 J 1000p 50V Ceramic AD
C7943 95CC10Q0CQ105 J 1 25V Ceramic AE
C7944 95CC10Q0CQ105 J 1 25V Ceramic AE
C7951 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C7952 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C7953 95CC3150DR471 J 470(ZLH) 35V Electrolytic AK
C7955 95CC1095EQ104 J 0.1 50V Ceramic AC
C7956 95CC1095EQ104 J 0.1 50V Ceramic AC
C7957 95CC1095EQ104 J 0.1 50V Ceramic AC
å C7991 95CC1385QS102 J 1000p(E) KX Ceramic AE
(LC-45GX6U/6T)
å C7992 95CC1385QS102 J 1000p(E) KX Ceramic AE
(LC-45GX6U/6T)
RESISTORS
R6101 95CR3133AC184 J 180k 1/4W Resistor AC
R6102 95CR3133AC184 J 180k 1/4W Resistor AC
R6103 95CR3133AC184 J 180k 1/4W Resistor AC
R6105 95CR3121TC273 J 27k 1/8W Resistor AB
R6106 95CR3131AC392 J 3.9k 1/4W Resistor AB
R6107 95CR3121TC331 J 330 1/8W Resistor AB
R6108 95CR3121TC333 J 33k 1/8W Resistor AB
R6109 95CR3131AC000 J 0 1/4W Resistor AB
R6110 95CR3121TC222 J 2.2k 1/8W Resistor AB
R6111 95CR3127TC822 J 8.2k 1/10W Resistor AC
R6112 95CR3121TC273 J 27k 1/8W Resistor AB
R6114 95CR3131AC392 J 3.9k 1/4W Resistor AB
R6117 95CR3121TC561 J 560 1/8W Resistor AB
R6118 95CR3121TC101 J 100 1/8W Resistor AB
R6120 95CR3121TC223 J 22k 1/8W Resistor AB
R6121 95CR3131AC471 J 470 1/4W Resistor AB
R6122 95CR3121TC332 J 3.3k 1/8W Resistor AB
R6123 95CR3127TC153 J 15k 1/10W Resistor AC
R6124 95CR3127TC222 J 2.2k 1/10W Resistor AC
R6125 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6127 95CR3123TC154 J 150k 1/8W Resistor AB
R6130 95CR3133AC474 J 470k 1/4W Resistor AC
R6131 95CR3133AC474 J 470k 1/4W Resistor AC
R6132 95CR3133AC474 J 470k 1/4W Resistor AC
R6133 95CR3133AC684 J 680k 1/4W Resistor AC
R6134 95CR3133AC564 J 560k 1/4W Resistor AC
R6135 95CR3133AC564 J 560k 1/4W Resistor AC
R6136 95CR3121TC333 J 33k 1/8W Resistor AB
R6137 95CR3121TC223 J 22k 1/8W Resistor AB
R6138 95CR3121TC103 J 10k 1/8W Resistor AB
R6140 95CR3123TC104 J 100k 1/8W Resistor AB
R6141 95CR3133AC334 J 330k 1/4W Resistor AC
R6142 95CR3133AC334 J 330k 1/4W Resistor AC
R6143 95CR3133AC394 J 390k 1/4W Resistor AC
R6144 95CR3121TC393 J 39k 1/8W Resistor AB
R6151 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6152 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6153 95CR3121TC222 J 2.2k 1/8W Resistor AB
R6154 95CR3127TC101 J 100 1/10W Resistor AC
R6155 95CR3127TC102 J 1k 1/10W Resistor AC
R6156 95CR3127TC392 J 3.9k 1/10W Resistor AC
R6157 95CR3127TC102 J 1k 1/10W Resistor AC
R6158 95CR3121TC471 J 470 1/8W Resistor AB
R6160 95CR3121TC102 J 1k 1/8W Resistor AB
R6177 95CR3121TC100 J 10 1/8W Resistor AB
R6178 95CR3131AC220 J 22 1/4W Resistor AB
R6180 95CR3121TC273 J 27k 1/8W Resistor AB
R6181 95CR3131AC220 J 22 1/4W Resistor AB
R6182 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6183 95CR3127TC103 J 10k 1/10W Resistor AC
R6184 95CR3121TC681 J 680 1/8W Resistor AB
R6185 95CR3127TC223 J 22k 1/10W Resistor AC
R6186 95CR3123TC104 J 100k 1/8W Resistor AB
R6187 95CR3121TC470 J 47 1/8W Resistor AB
R6201 95CR3133AC184 J 180k 1/4W Resistor AC
R6202 95CR3133AC184 J 180k 1/4W Resistor AC
R6203 95CR3133AC184 J 180k 1/4W Resistor AC
R6205 95CR3121TC273 J 27k 1/8W Resistor AB
R6206 95CR3131AC392 J 3.9k 1/4W Resistor AB
R6207 95CR3121TC331 J 330 1/8W Resistor AB
R6208 95CR3121TC333 J 33k 1/8W Resistor AB
R6209 95CR3131AC000 J 0 1/4W Resistor AB
R6210 95CR3121TC222 J 2.2k 1/8W Resistor AB
R6211 95CR3127TC822 J 8.2k 1/10W Resistor AC
R6212 95CR3121TC273 J 27k 1/8W Resistor AB
R6214 95CR3131AC392 J 3.9k 1/4W Resistor AB
R6217 95CR3121TC561 J 560 1/8W Resistor AB
R6218 95CR3121TC101 J 100 1/8W Resistor AB
R6220 95CR3121TC223 J 22k 1/8W Resistor AB
R6221 95CR3131AC471 J 470 1/4W Resistor AB
R6222 95CR3121TC332 J 3.3k 1/8W Resistor AB
R6223 95CR3127TC153 J 15k 1/10W Resistor AC
R6224 95CR3127TC222 J 2.2k 1/10W Resistor AC
R6225 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6227 95CR3123TC154 J 150k 1/8W Resistor AB
R6230 95CR3133AC474 J 470k 1/4W Resistor AC
R6231 95CR3133AC474 J 470k 1/4W Resistor AC
R6232 95CR3133AC474 J 470k 1/4W Resistor AC
R6233 95CR3133AC684 J 680k 1/4W Resistor AC
R6234 95CR3133AC564 J 560k 1/4W Resistor AC
R6235 95CR3133AC564 J 560k 1/4W Resistor AC
R6236 95CR3121TC333 J 33k 1/8W Resistor AB
R6237 95CR3121TC223 J 22k 1/8W Resistor AB
R6238 95CR3121TC103 J 10k 1/8W Resistor AB
R6240 95CR3123TC104 J 100k 1/8W Resistor AB
R6241 95CR3133AC334 J 330k 1/4W Resistor AC
R6242 95CR3133AC334 J 330k 1/4W Resistor AC
R6243 95CR3133AC394 J 390k 1/4W Resistor AC
R6244 95CR3121TC393 J 39k 1/8W Resistor AB
R6251 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6252 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6253 95CR3121TC222 J 2.2k 1/8W Resistor AB
R6254 95CR3127TC101 J 100 1/10W Resistor AC
R6255 95CR3127TC102 J 1k 1/10W Resistor AC
R6256 95CR3127TC392 J 3.9k 1/10W Resistor AC
R6257 95CR3127TC102 J 1k 1/10W Resistor AC
R6258 95CR3121TC471 J 470 1/8W Resistor AB
R6260 95CR3121TC102 J 1k 1/8W Resistor AB
R6277 95CR3121TC100 J 10 1/8W Resistor AB
R6278 95CR3131AC220 J 22 1/4W Resistor AB
R6280 95CR3121TC273 J 27k 1/8W Resistor AB
R6281 95CR3131AC220 J 22 1/4W Resistor AB
R6282 95CR3121TC472 J 4.7k 1/8W Resistor AB
R6283 95CR3127TC103 J 10k 1/10W Resistor AC
R6284 95CR3121TC681 J 680 1/8W Resistor AB
R6285 95CR3127TC223 J 22k 1/10W Resistor AC
R6286 95CR3123TC104 J 100k 1/8W Resistor AB
R6287 95CR3121TC470 J 47 1/8W Resistor AB
R6301 95CR3133AC184 J 180k 1/4W Resistor AC
R6302 95CR3133AC184 J 180k 1/4W Resistor AC
R6303 95CR3133AC184 J 180k 1/4W Resistor AC
R6305 95CR3121TC273 J 27k 1/8W Resistor AB
R6306 95CR3131AC332 J 3.3k 1/4W Resistor AB
R6307 95CR3121TC331 J 330 1/8W Resistor AB
R6308 95CR3121TC332 J 3.3k 1/8W Resistor AB
R6309 95CR3131AC000 J 0 1/4W Resistor AB
R6310 95CR3121TC222 J 2.2k 1/8W Resistor AB
R6311 95CR3127TC123 J 12k 1/10W Resistor AC
R6312 95CR3127TC473 J 47k 1/10W Resistor AC
R6314 95CR3131AC332 J 3.3k 1/4W Resistor AB
R6317 95CR3121TC561 J 560 1/8W Resistor AB
R6318 95CR3121TC101 J 100 1/8W Resistor AB
R6320 95CR3121TC223 J 22k 1/8W Resistor AB
R6321 95CR3131AC471 J 470 1/4W Resistor AB
RDENCA083WJZZ
RDENCA086WJZZ
POWER SUPPLY UNIT(Continued)
