Sharp LC-45GX6U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
211
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
MISCELLANEOUS PARTS
å F7003 95CK7101AR2R0 J Fuse, AC250V 2A (382) AK
F7004 95CK7142AL001 J Fuse, DC450V 1A(DCP) AU
ASR1 95CM9017AZ001 J ACCESSORIES, AF
MINI SADDLE RMS-2V0-B
ASR2 95CM9017AZ001 J ACCESSORIES, AF
MINI SADDLE RMS-2V0-B
BEA7101 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7102 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7104 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7105 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7901 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7941 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
BEA7951 95CL5051AQ001 J BL02RN1R2N1A, Ferrite Beads AD
FG1 95CK2052PQ005 J Connector, AE
EARTH Terminal(M3) TP00370-41
FG2 95CK2052PQ005 J Connector, AE
EARTH Terminal(M3) TP00370-41
NTC7001 95CD7059AQ8R0 J NTC Thermistor AK
NTPD78R0LD6A1
P6101 95CK2051AQ002 J Connector, B2P3-VH AE
P7001 95CK2061AQ008 J Connector, B8P-VH AN
P7901 95CK2130BS005 J Connector, B11B-PASK-1 AN
å PC6101 95CH7148AS003 J PC123Y82FZM AH
å PC6201 95CH7148AS003 J PC123Y82FZM AH
å PC6301 95CH7148AS003 J PC123Y82FZM AH
å PC7001 95CH7136AS001 J PC3SF21YVZA AP
å PC7101 95CH7148AS003 J PC123Y82FZM AH
å PC7901 95CH7148AS003 J PC123Y82FZM AH
å PC7902 95CH7148AS003 J PC123Y82FZM AH
å PTC7101 95CD8002AQ120 J POSISTOR AP
PTH9M04BB222TS2F333
SHT1 95C0PKPS10310 J SILICONE Rubber Sheet TBM FB-45 AS
å TRA7001 95CD5013AQ616 J TRIODE AC SEMICONDUCTOR Switch AT
SM16JZ47
å Z7002 95CD7058AQ471 J TRANSIENT VoltagE SURGE AG
SUPPRESSOR ENC471
RDENCA083WJZZ
RDENCA086WJZZ
POWER SUPPLY UNIT(Continued)
