Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
213
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
CABINET AND MECHANICAL PARTS
(Continued)
26 GCOVAA916WJKA J Terminal Cover_Bottm AZ
27 GCOVAA918WJKA J Bracket Cover L AN
28 GCOVAA919WJKA J Bracket Cover R AN
29 HiNDPB174WJSA J Model Indicator AH
(LC-45GX6U)
29 HiNDPB248WJSA J Model Indicator
(LC-45GX6D)
29 HiNDPB249WJSA J Model Indicator
(LC-45GX6T)
30 LANGKA331WJZZ J Bracket Angle R AN
31 LANGKA332WJZZ J Bracket Angle L AN
32 LANGKA333WJFW J Fixing Metal, x2 AG
33 LX-EZA015WJF8 J Screw, x2 AA
34 LX-HZA025WJF7 J Screw, x62 AB
35 LX-HZA027WJF7 J Screw AC
36 LX-HZA029WJF7 J Screw, x4 AB
37 LX-HZA030WJF7 J Screw, x3 AB
38 NFANR0126CEZZ J FAN, x2 AT
39 PRDARA166WJFW J Heat Sink AN
40 PSLDMA546WJZZ J Shield, x6 (for FPC) AK
41 PSPAGA210WJZZ J Spacer AC
42 PSPAZA398WJKA J Spacer, x6 AK
43 PSPAZA551WJZZ J Spacer, x4 AD
44 QCNW-B441WJQZ J FFC (LCD CONT-TMDS RX)AC
45 QCNW-C634WJQZ J Connecting Cord (KM) AK
46 QCNW-C635WJQZ J
Connecting Cord (MN1,MN3), x2
AN
47 QCNW-C636WJQZ J Connecting Cord (RM) AM
48 QCNW-C637WJQZ J Connecting Cord (NP1-4) AS
49 QCNW-C639WJQZ J Connecting Cord (AC) AF
50 QCNW-C640WJQZ J Connecting Cord (TV) AH
51 QCNW-C642WJQZ J Connecting Cord (MC) AM
52 QCNW-C643WJQZ J Connecting Cord (SO) AN
53 QCNW-C644WJQZ J Connecting Cord (LB/LT) AX
54 QCNW-C645WJQZ J Connecting Cord (SP) AS
55 QCNW-C646WJQZ J Connecting Cord (DC) AM
56 QCNW-C901WJQZ J
Connecting Cord, SP Wire (Short)
AH
57 QCNW-C902WJQZ J
Connecting Cord, SP Wire (Long)
AK
58 QPWBHC639WJQZ J
FPC (LCD CONT-TMDX RX), x2
AN
59 QPWBHC640WJQZ J FPC (LCD CONT TOP-BOT)AX
60 QPWBMC494WJPZ J Panel FPC Top, x2 AM
61 QPWBMC534WJPZ J Panel FPC Bottom, x2 AP
62 RCORFA012WJZZ J Core AG
63 RCORFA039WJZZ J Core, x4 for FPC AG
64 RDENCA083WJZZ – POWER SUPPLY Unit —
(LC-45GX6U/6T)
64 RDENCA086WJZZ – POWER SUPPLY Unit —
(LC-45GX6D)
65 XBBS830P08000 J Screw, x2 AA
66 XBBS840P10000 J Screw, x2 AB
67 XBBS840P18000 J Screw, x4 for Speaker Unit AB
68 XBBSN40P12JS0 J Screw, x8 for Center Angle AB
69 XBBSN50P12JS0 J Screw, x4 for STAND AF
70 XCBS940P25000 J Screw, x5 (STAND) AB
71 XEBS930P10000 J Screw, x3 AA
72 XEBS940P14000 J Screw, x4 for Bracket Cover AB
73 XEBS940P20000 J Screw, x14 AB
74 XEBSN30P10000 J Screw, x19 AA
75 GCOVAA923WJKA J Cover AN
76 LANGQA014WJFW J Fixing Metal AM
77 LX-BZ3434CEFN J Screw AB
78 NSFTZ0134CEFW J Shaft AD
79 XBPS730P08JS0 J Screw AB
80 LANGQA013WJFW J Fixing Metal AH
81 XBPS730P08JS0 J Screw AB
82 XBSS830P08000 J Screw AA
83 LHLDFA021WJZZ J Holder AC
10-3 PSPAHA455WJZZ J Spacer, x4 AA
12 DUNTKC470VJ01 J
TMDS RX Unit (LC-45GX6U)
BZ
12 DUNTKC470VJ08 J
TMDS RX Unit (LC-45GX6D)
12 DUNTKC470VJ10 J
TMDS RX Unit (LC-45GX6T)
13 DUNTKC471UJ01 –
INVERTER 1 Unit (LC-45GX6U)
—
13 DUNTKC471UJ08 –
INVERTER 1 Unit (LC-45GX6D)
—
13 DUNTKC471UJ10 –
INVERTER 1 Unit (LC-45GX6T)
—
14 DUNTKC472UJ01 –
INVERTER 2 Unit (LC-45GX6U)
—
14 DUNTKC472UJ08 –
INVERTER 2 Unit (LC-45GX6D)
—
14 DUNTKC472UJ10 –
INVERTER 2 Unit (LC-45GX6T)
—
15 DUNTKC473UJ01 –
INVERTER 3 Unit (LC-45GX6U)
—
15 DUNTKC473UJ08 –
INVERTER 3 Unit (LC-45GX6D)
—
15 DUNTKC473UJ10 –
INVERTER 3 Unit (LC-45GX6T)
—
16 DUNTKC474UJ01 –
INVERTER 4 Unit (LC-45GX6U)
—
16 DUNTKC474UJ08 –
INVERTER 4 Unit (LC-45GX6D)
—
16 DUNTKC474UJ10 –
INVERTER 4 Unit (LC-45GX6T)
—
17 DUNTKC475UJ01 – MOTOR CONTROL Unit —
(LC-45GX6U)
17 DUNTKC475UJ08 – MOTOR CONTROL Unit —
(LC-45GX6D)
17 DUNTKC475UJ10 – MOTOR CONTROL Unit —
(LC-45GX6T)
18 DUNTKC476UJ01 – R/C LED Unit (LC-45GX6U) —
18 DUNTKC476UJ08 – R/C LED Unit (LC-45GX6D) —
18 DUNTKC476UJ10 – R/C LED Unit (LC-45GX6T) —
19 DUNTKC478UJ01 J
TOP LCD CONTROLLER Unit
CM
(LC-45GX6U)
19 DUNTKC478UJ11 J
TOP LCD CONTROLLER Unit
(LC-45GX6D)
19 DUNTKC478UJ12 J
TOP LCD CONTROLLER Unit
(LC-45GX6T)
20 DUNTKC479UJ01 J
BOTTOM LCD CONTROLLER Unit
BU
(LC-45GX6U)
20 DUNTKC479UJ11 J
BOTTOM LCD CONTROLLER Unit
(LC-45GX6D)
20 DUNTKC479UJ12 J
BOTTOM LCD CONTROLLER Unit
(LC-45GX6T)
21 DUNTKC504VJ01 – LINE FILTER Unit —
(LC-45GX6U)
21 DUNTKC504VJ08 – LINE FILTER Unit —
(LC-45GX6D)
21 DUNTKC504VJ10 – LINE FILTER Unit —
(LC-45GX6T)
22 DUNTKC506UJ01 – DC/DC Unit —
(LC-45GX6U)
22 DUNTKC506UJ08 – DC/DC Unit —
(LC-45GX6D)
22 DUNTKC506UJ10 – DC/DC Unit —
(LC-45GX6T)
23 DUNTKC507UJ01 – CS CONTROL Unit —
(LC-45GX6U)
23 DUNTKC507UJ08 – CS CONTROL Unit —
(LC-45GX6D)
23 DUNTKC507UJ10 – CS CONTROL Unit —
(LC-45GX6T)
24 DUNTKC508UJ01 – KEY Unit —
(LC-45GX6U)
24 DUNTKC508UJ08 – KEY Unit —
(LC-45GX6D)
24 DUNTKC508UJ10 – KEY Unit —
(LC-45GX6T)
25
Not Available
– Speaker Unit —
25-1 CHLDZA421WJ01 J Bracket R Ass’y AQ
25-1-1 LHLDZA421WJKA J Bracket R AQ
25-1-2 PSPAGA221WJZZ J Spacer AE
25-2 CHLDZA422WJ01 J Bracket L Ass’y AR
25-2-1 LHLDZA422WJKA J Bracket L AQ
25-2-2 PSPAGA222WJZZ J Spacer AE
25-3 LX-BZA075WJ01 J Screw, x4 AE
25-4 RSP-ZA086WJN2 J Speaker BX
To Next Page
