12
Preparation
4
5
Attaching the clamp and bundling the cables with the clamp
Closing the terminal cover
Cable clamp
Insert the cable clamp in the hole on the Display as shown.
Cables come
out from the
small opening.
Fasten the speaker
cable with the holder.
LC-45GX6U(E)-001-019 04.7.8, 8:41 AM12
