LC-46DH65E/S, LC-46DH66E
1 – 1
LC46DH65E
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Item
46" LCD COLOUR TV,
Model: LC-46DH65E, LC-46DH65S, LC-46DH66E
LCD panel
46" Advanced Super View & BLACK TFT LCD
Resolution
2,073,600 pixels (1,920 1,080)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV Function TV-Standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF E2–E69 ch, F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: IR A ch–E69 ch)
CATV Hyper-band, S1–S41 ch
TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Brightness 450 cd/m
2
Viewing angles H: 176°,V: 176°
Audio amplifier
10 W 2
Speaker
(40 mm 110 mm) 2
Terminals Antenna
UHF/VHF 75
Ω Din type (Analogue & Digital)
RS-232C D-Sub 9 pin male connector
EXT1 SCART (AV input, Y/C input, RGB input, TV output)
EXT2 SCART (AV input/monitor output, Y/C input, AV Link, RGB input)
EXT3 COMPONENT IN: Y/P
B(CB)/PR(CR), RCA pin (AUDIO R/L)
EXT4 15 pin mini D-sub, Ø 3.5 mm jack*
HDMI1 (EXT5) HDMI
HDMI2 (EXT6) HDMI, Ø 3.5 mm jack*
HDMI3 (EXT7) HDMI
EXT8 RCA pin (AV input)
USB USB 2.0
DIGITAL AUDIO OUTPUT Optical SPDIF Digital audio output
C. I. (Common Interface) EN50221, R206001
OUTPUT RCA pin (AUDIO R/L)
Headphones Ø 3.5 mm jack (Audio output)
OSD language Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian,
Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish,
Swedish, Turkish, Ukrainian
Power Requirement AC 220–240 V, 50 Hz
Power Consumption
(Method IEC62087)
200 W (0.5 W Standby)
Weight 21.2 kg (Without stand), 24.2 kg (With stand)
Operating temperature
0°Cto+40°C
The HDMI2 and EXT4 terminals can both use the same audio input terminal.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
NOTE
Refer to the inside back cover for dimensional drawings.
Optional accessory
*
The listed optional accessories are available for this LCD
colour TV. Please purchase them at your nearest shop.
Additional optional accessories may be available in the near
future. When purchasing, please read the newest catalogue for
compatibility and check the availability.
No. Part name Part number
1
Wall mount bracket
(LC-46DH65E, LC-46DH65S,
LC-46DH66E)
AN-52AG4
To Next Page
