Sharp LC-46DH65E User Manual

LC-46DH65E/S, LC-46DH66E
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE266FM01 AR N R KEY Unit
N DUNTKE685FM06 N R MAIN Unit
N DUNTKE687FM06 N R LED Unit
N RDENCA308WJQZ N S POWER Unit (Unit Replacement Item)
[2] LCD PANEL
N R1LK460D3LW6AY N J 46" LCD Panel Module
[3] DUNTKE266FM01 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug 5pin (KM)
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch CH-UP
S152 QSW-K0003AJZZ+ AB J Switch CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch INPUT
S154 QSW-K0003AJZZ+ AB J Switch VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch VOL-DOWN
S156 QSW-K0003AJZZ+ AB J Switch MENU
S157 QSW-K0003AJZZ+ AB J Switch POWER
[4] DUNTKE685FM06 (MAIN Unit)
C502 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C503 VCEASY1CN477MY AD J Capacitor 470 16V Electrolytic
C504 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C505 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C506 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C507 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C511 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C512 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C513 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C514 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C515 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C516 VCEASY1CN477MY AD J Capacitor 470 16V Electrolytic
C517 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C518 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C519 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C524 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C525 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C528 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C529 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C530 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C532 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C533 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C534 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C535 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C538 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C539 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C540 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C541 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C542 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C543 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C544 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C545 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C547 VCKYCZ1HB102KY AB J
Capacitor 1000p 50V Ceramic
C548 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C549 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C550 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C551 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C552 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C553 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C556 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C557 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C558 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C560 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C561 VCERMZ1CN107MY AD J Capacitor 100 16V Electrolytic
C562 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C563 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C565 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C566 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C567 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C568 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C572 VCEASX1CN226MY AC J Capacitor 22 16V Electrolytic
C573 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C574 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C575 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
