LC-46SB57U/LC-52SB57U
4 – 7
[2] REMOVING OF MAJOR PARTS (LC-52SB57U)
1. Removing of Stand Unit and Rear Cabinet Ass’y.
1. Remove the 4 lock screws and detach the Stand Unit.
2. Remove the 4 VESA Hole Covers .
3. Remove the 1 lock screw , 1 lock screw , 12 lock screws and detach the Rear Cabinet Ass’y.
5
4
1
3
2
Front Cabinet Ass'y
Rear Cabinet
Ass'y
Stand Unit
