LC-60LE630U/U(A), LC-70LE735U
4 – 2
3. Entering and exiting the adjustment process mode
1) Before entering the adjustment process mode, the AV position RESET in the video adjustment menu.
2) While holding down the “VOL (–)” and “INPUT” keys at a time, plug in the AC cord of the main unit to turn on the power.
The letter “<K>” appears on the screen.
3) Next, hold down the “VOL (–)” and “CH ( )” keys at a time.
(The “VOL (–)” and “CH ( )” keys should be pressed and held until the display appears.)
Multiple lines of white characters appearing on the display indicate that the unit is now in the adjustment process mode.
When you fail to enter the adjustment process mode (the display is the same as normal startup), retry the procedure.
4) To exit the adjustment process mode after the adjustment is done, unplug the AC cord from the outlet to make a forced shutdown. (When the
power was turned off with the remote controller, once unplug the AC cord and plug it again. In this case, wait 10 seconds or so before plugging.)
CAUTION: Use due care in handling the information described here lest your users should know how to enter the adjustment process mode. If the
settings are tampered in this mode, unrecoverable system damage may result.
4. Remote controller key operation in adjustment process mode
*Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.
5. List of adjustment process mode menu
Remote controller key Main unit key Function
CH ( / )
CH ( / )
Moving an item (line) by one (UP/DOWN)
VOL (+/–) VOL (+/–) Changing a selected item setting (+1/ –1)
Cursor (UP/DOWN) ————— Turing a page (PREVIOUS/NEXT)
Cursor (LEFT/RIGHT) ————— Changing a selected line setting (+10/ –10)
INPUT ————— Input switching (toggle switching)
ENTER ————— Executing a function
Page Line Item Description Remarks
1 1 Main Version Main software version BL: boot loader version
2 Check Sum Flash check sum
3 PANEL Version
4 TEMP SENSOR
5 NORMAL STANDBY CAUSE Normal standby cause
6 ERROR STANDBY CAUSE Error standby cause
2 1 Factory Init Initialization to factory settings
2 Inch Setting Inch size
3 Public Mode Public mode Not available
4 Operation Acutime Accumulated operation time
5 RESET Reset
31RF-AGC ADJ Not available
2TUNER ADJ Not available
3 PAL ADJ Not available
4RF AGC Not available
5 TUNER Level Not available
6 CVBS Level Not available
7VIF Not available
8 VIDEO AGC Not available
4 1 COMP SD ADJ Component 15K picture level adjustment
2 Y OFFSET
3Cb OFFSET
4 Cr OFFSET
5 Y GAIN
6Cb GAIN
7Cr GAIN
8 RESET ADJUSTMENT Reset
5 1 COMP HD ADJ Component 33K picture level adjustment
2 Y OFFSET
3 Pb OFFSET
4Pr OFFSET
5 Y GAIN
6Pb GAIN
7Pr GAIN
8 RESET ADJUSTMENT Reset
To Next Page
