Sharp LC-60LE630U User Manual

LC-60LE630U/U(A), LC-70LE735U
4 – 3
6 1 RGB ADJ Analog RGB picture level adjustment
2 G OFFSET
3 B OFFSET
4 R OFFSET
5 G GAIN
6 B GAIN
7 R GAIN
8 RESET ADJUSTMENT Reset
7 1 IN POINT LOW_D Adjustment point1 at Dynamic mode
2 IN POINT HIGH_D Adjustment point2 at Dynamic mode
3 R LEVEL LOW_D WB adjustment Point 1, R adjustment value at Dynamic mode
4 G LEVEL LOW_D WB adjustment Point 1, G adjustment value at Dynamic mode
5 B LEVEL LOW_D WB adjustment Point 1, B adjustment value at Dynamic mode
6 R LEVEL HIGH_D WB adjustment Point 2, R adjustment value at Dynamic mode
7 G LEVEL HIGH_D WB adjustment Point 2, G adjustment value at Dynamic mode
8 B LEVEL HIGH_D WB adjustment Point 2, B adjustment value at Dynamic mode
9 R LEVEL MAX_D WB adjustment Point Max., R adjustment value at Dynamic mode
10 G LEVEL MAX_D WB adjustment Point Max., G adjustment value at Dynamic mode
11 B LEVEL MAX_D WB adjustment Point Max., B adjustment value at Dynamic mode
8 1 IN POINT LOW Adjustment point1
2 IN POINT HIGH Adjustment point2
3 R LEVEL LOW WB adjustment Point 1, R adjustment value
4 G LEVEL LOW WB adjustment Point 1, G adjustment value
5 B LEVEL LOW WB adjustment Point 1, B adjustment value
6 R LEVEL HIGH WB adjustment Point 2, R adjustment value
7 G LEVEL HIGH WB adjustment Point 2, G adjustment value
8 B LEVEL HIGH WB adjustment Point 2, B adjustment value
9 R LEVEL MAX WB adjustment Point Max., R adjustment value
10 G LEVEL MAX WB adjustment Point Max., G adjustment value
11 B LEVEL MAX WB adjustment Point Max., B adjustment value
12 ADJ DATA STORE Execute
13 RESET ADJUSTMENT Reset
9 1 EEP CLEAR Clear all setting data of flash memory
2 AUTO INSTALLATION SW
3 STANDBY CAUSE RESET Reset STANDBY CAUSE
4 DESTINATION Destination of factory Initialization
5 L ERR RESET Number of termination due to lamp error and Reset
6 L ERR STOP Stop the detection of amp error detection
7 TEMP CAUTION Threshold level of temperature caution
8 TEMP SHUTDOWN Threshold level of temperature protection
10 1 VCOM ADJ Not available
2 TEST PATTERN Test pattern
3 DIMMER DIMMER setting (64)
Page Line Item Description Remarks

Sharp LC-60LE630U Specifications

General

Brand	Sharp
Model	LC-60LE630U
Category	LCD TV
Language	English
