Sharp LC-60LE635E Service Manual

LC-60LE635E/636E/638E (1st Edition)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1204 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide (excepe LC-60LE636E
R1205 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide (excepe LC-60LE636E
R1206 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide (excepe LC-60LE636E
R1207 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide (excepe LC-60LE636E
R2027 VRS-CZ1JF272JY AA J Resistor 2.7k 1/16W Metal Oxide
R2711 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2712 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2713 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2721 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2722 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2723 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2724 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R3358 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3422 VRS-CZ1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide (excepe LC-60LE6
R3423 VRS-CZ1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide (excepe LC-60LE6
R3533 VRK-SB1FF470JY AA J Resistor 47 1/32W Metal Composition
R3534 VRK-SB1FF470JY AA J Resistor 47 1/32W Metal Composition
R3535 VRK-SB1FF470JY AA J Resistor 47 1/32W Metal Composition
R3536 VRK-SB1FF470JY AA J Resistor 47 1/32W Metal Composition
R3537 VRK-SB1FF470JY AA J Resistor 47 1/32W Metal Composition
R3538 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R3539 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R3540 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R3541 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R3542 VRK-SA1JF000JY AB J Resistor 0 1/16W Metal Composition
R3543 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3544 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3545 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3546 VRS-CZ1JF241FY AB J Resistor 240 1/16W Metal Oxide
R3547 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3548 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R4402 VRK-SB1FF473JY AB J Resistor 47k 1/32W Metal Composition (for LC-60L
R4455 VRK-SA1JF000JY AB J Resistor 0 1/16W Metal Composition (excepe LC-60
R4457 VRK-SA1JF000JY AB J
Resistor 0 1/16W Metal Composition (for LC-60LE6
R4459 V
RK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition (excepe LC-6
TU1102 RTUDWA029WJQZ P Tuner (excepe LC-60LE636E)
TU1104 RTUDAA072WJQZ P Tuner (for LC-60LE636E)
[4] DUNTKF800FM52 (KEY Unit)
D151 RH-EX1394CEZZY AB N J Diode UDZSFVTE-175.6B
D152 RH-EX1394CEZZY AB N J Diode UDZSFVTE-175.6B
D153 RH-EX1394CEZZY AB N J Diode UDZSFVTE-175.6B
P151 QPLGNA324WJZZY AC J Plug
R151 VRS-CY1JF822JY AA N J Resistor 8.2k 1/16W Metal Oxide
R152 VRS-CY1JF123JY AA N J Resistor 12k 1/16W Metal Oxide
R153 VRS-CY1JF822JY AA N J Resistor 8.2k 1/16W Metal Oxide
R154 VRS-CY1JF123JY AA N J Resistor 12k 1/16W Metal Oxide
S151 QSW-KA037WJZZY AC J Switch
S152 QSW-KA037WJZZY AC J Switch
S153 QSW-KA037WJZZY AC J Switch
S154 QSW-KA037WJZZY AC J Switch
S155 QSW-KA037WJZZY AC J Switch
S156 QSW-KA037WJZZY AC J Switch
S157 QSW-KA037WJZZY AC J Switch
[5] CABINET PARTS
1 CCABAC821WJ21 N P Front Cabinet Ass'y
1-1 GCABAC821WJ2A N P Front Cabinet
1-2 HDECQB671WJ2A N P Front Decoration
1-3 PSHEZA312WJZZ P Protect Top
1-4 PSHEZA313WJZZ P Protect Side
1-5 PSHEZA321WJZZ P Protect Bottom
1-6 PSHEZA342WJZZ N P Protect Edge
1-7 PSHEZA345WJZZ N P Tape
2 GCABBC031WJ1A N P Rear Cabinet Ass'y
3 GCOVAD966WJ1A P RC_OPC COV
4 GCOVAE203WJ2A N P KEY Cover
5 HiNDPE032WJSB N P P_INDICATOR/BTM (except U.K.)
6 HiNDPE035WJSA P P_INDICATOR/BCK
7 HiNDPE117WJSB N P P_INDICATOR/SID
8 LANGKD148WJFW P Terminal Angle (Bottom) (except LC-60LE636E)
8 LANGKD192WJFW P Terminal Angle (Bottom) (for LC-60LE636E)
9 LHLDWA138WJKZ AC J Wire Holder
10 JBTN-A936WJ2A N P KEY BTN
11 LX-BZA207WJF7 AA J Screw
12 PSLDMB751WJFW P MAIN PWB Shield
13 LANGKD127WJFW AD J Fixing Metal Angle
14 LANGKD265WJ2W - P S-T-Angle
15 LANGKD281WJ2W N P CENTER ANG
16 LHLDWA282WJKZ AC J Wire Holder
17 QCNW-L587WJQZ AE J Connecting Cord (PL)
18 QCNW-L608WJQZ AM J Connecting Cord (PD)
19 LHLDWA294WJUZ AC J Wire Holder
20 QCNW-L720WJQZ N P Connecting Cord (LV)
21 QCNWN2731TPZZ AF J Connecting Cord (80P:MDL-CTL)
[3] DUNTKF733FM55/56/57 (MAIN Unit)
